Electrical Installation - Eton PRO 100 X Anleitung

Whenever you run wires through sheet metal, use tape or grommets to properly
insulate the metal edges from cable jackets. This technique prevents chafing
and possible short circuits that could damage an amplifier or the loudspeakers.
Please use only the enclosed crimp-type terminals when connecting
and do not solder them to avoid possible damage to the compo- nents.
1. Follow the wiring diagrams figures 5 and 6 to connect the loud-
speaker system to your automobile radio and possibly to an ampli-
fier. Be very careful of correct polarity of all connections.
(+ to +, - to -)
The tweeters should only be installed through a crossover.
2. Replace the automobile battery connector and test the loudspeaker
system.
Caution: Do not apply power to the tweeters without first installing
crossovers.

ELECTRICAL INSTALLATION
