EuroLite LED IP T2000 TCL Bedienungsanleitung Seite 34

116 120 74 78 45% 47%
121 125 79 7D 47% 49%
126 130 7E 82 49% 51%
131 135 83 87 51% 53%
136 140 88 8C 53% 55%
141 145 8D 91 55% 57%
146 150 92 96 57% 59%
151 155 97 9B 59% 61%
156 160 9C A0 61% 63%
161 165 A1 A5 63% 65%
166 170 A6 AA 65% 67%
171 175 AB AF 67% 69%
176 180 B0 B4 69% 71%
181 185 B5 B9 71% 73%
186 190 BA BE 73% 75%
191 195 BF C3 75% 76%
196 200 C4 C8 77% 78%
201 255 C9 FF 79% 100% S No function
Control-channel 7 - Speed internal programs (AUTO 1 - 5)
Decimal Hexad. Percentage S/F
0 255 00 FF 0% 100%
Control-channel 8 - Color-change linear
Decimal Hexad. Percentage S/F
0 10 00 0A 0% 4%
11 11 0B 0B 4% 4%
12 50 0C 32 5% 20%
51 51 33 33 20% 20%
52 90 34 5A 20% 35%
91 91 5B 5B 36% 36%
92 130 5C 82 36% 51%
131 131 83 83 51% 51%
132 170 84 AA 52% 67%
171 171 AB AB 67% 67%
172 210 AC D2 67% 82%
211 211 D3 D3 83% 83%
212 250 D4 FA 83% 98%
251 255 FB FF 98% 100%
Control-channel 9 - Dimmer curves
Decimal Hexad. Percentage S/F
0 10 00 0A 0% 6%
11 20 0B 14 6% 18%
21 30 15 1E 18% 29%
31 40 1F 28 30% 41%
41 50 29 32 42% 53%
51 60 33 3C 53% 65%
61 70 3D 46 65% 76%
71 80 47 50 77% 88%
81 90 51 5A 89% 100%
91 255 5B FF 89% 100%
S Green
S Blue
S Red
S Green
S Blue
S Yellow
S Pink
S Cyan
S Orange
S Violet
S Golden
S WHITE color temperature 2700 K
S WHITE color temperature 3200 K
S WHITE color temperature 4000 K
S WHITE color temperature 5500 K
S WHITE color temperature 6500 K
S RGB
F Decreasing speed
S No function
S Blue
F Red 0% / green increasing / blue 100%
S Cyan
F Red 0% / green 100% / blue decreasing
S Green
F Red increasing / green 100% / blue 0%
S Yellow
F Red 100% / green decreasing / blue 0%
S Red
F Red 100% / green 0% / blue increasing
S Magenta
F Red decreasing / green 0% / blue 100%
S Blue
S Control Board setting dimmer curve
S Linear dimmer curve, response characteristics of LED
S Square dimmer curve, response characteristics of LED
S Inverse square dimmer curve, response characteristics of LED
S S-shaped dimmer curve, response characteristics of halogen LED
S Linear dimmer curve, response characteristics of halogen lamp
S Square dimmer curve, response characteristics of halogen lamp
S Inverse square dimmer curve, response characteristics of halogen lamp
S S-shaped dimmer curve, response characteristics of halogen lamp
S Control Board setting dimmer curve
34/36
Feature
Feature
Feature
00101939, Version 1.0
