3.3 Reset of factory default settings

3.4 SD card slot

Before usage of micro SD card the card must be formatted.

3.5 Audio output / Audio input

Audio input
Audio output

3.6 Auto-Back-Focus button

The camera has a mobile and motorized mounted imager. The distance between imager and lens
can be adjusted automatically via the auto back focus button, the focus point is carefully adjusted.
The auto back focus button is also in the web interface as a software button available (button
"ABF / AF").
1. Please disconnect the camera form power
connection.
2. Press the "Reset" button on the camera
and keep it pressed.
3. Now connect the power supply to the
camera (2-pin power supply or Power over
Ethernet), and hold the "Reset" button
pressed for another 30 seconds.
Max. SD card size:
3,5 mm phone jack
Mikrofon / Line
Impedance 10 kOhm
Voltage 2,0 Vpp
3,5 mm phone jack
Impedance 600 Ohm
Voltage 2,0 Vpp
18
128 GByte
