Replacing of the illuminant
1. unscrew and wash the lamp cover and wipe it dry.
2. unscrew the light bulb from the socket, replace the bulb. Choose a high
temperature bulb ( 300℃ ) with the following parameters:
Voltage230V
Power 25W
Thread E14.
3. Do not use any other type of bulb.
4. Screw the bulb in, Check its proper position in the ceramic socket.
5. Replace the lamp cover.
According to the EU regulation No. 244/2009, your appliance is classified as a
household appliance in accordance with the ecodesign requirements for non-
directional household lamps. This means that bulbs, which are used in
household appliances, must not be used to illuminate domestic establishments.
Removing of the door
1. Open the door and push the safety
catch upwards.
2. Close the door slightly.
3. Lift the door and pull it towards
your direction.
4. To reassemble proceed in reverse
order.
5. Check that the groove of the hinge
bracket is positioned properly in its
guide.
6. After reassembling the door close the safety catch carefully.
7. If the safety catch is not closed properly you will damage the hinges when
closing the door.
Removing of the glass panel
1. Unscrew and unfasten the bracket
latch that is in the corner at the top
of the door.
2. Take out the glass from the second
blocking mechanism and remove it.
38
