Oven
3
1 Rotary knob hotplate – rear left
2 Rotary knob hotplate – front left
3 Rotary knob oven/function control
4 Rotary knob oven /temperature control
5 Rotary knob hotplate /front right
6 Rotary knob hotplate - rear right
A Control light hob - red
4
Before the first use
1. Remove all packaging material.
2. Clean the oven inside from all protective agents.
3. Take out the supplied accessories and clean them with warm water and
washing-up liquid.
MAIN COMPONENTS
OPERATION
33
7 Ø 145 mm; 1000W
8 Ø 180 mm; 1500W
9 Ø 180 mm; 2000W
10 Ø 145 mm; 1000W
B Control light oven- orange
3
4
