14 | English
 Secure the workpiece. A workpiece clamped with clamp-
ing devices or in a vice is held more secure than by hand.
 Always wait until the machine has come to a complete
stop before placing it down. The tool insert can jam and
lead to loss of control over the power tool.
 Do not open the battery. Danger of short-circuiting.
Protect the battery against heat, e. g., against
continuous intense sunlight, fire, water, and
moisture. Danger of explosion.
 In case of damage and improper use of the battery, va-
pours may be emitted. Ventilate the area and seek
medical help in case of complaints. The vapours can irri-
tate the respiratory system.
 Use the battery only in conjunction with your Bosch
power tool. This measure alone protects the battery
against dangerous overload.
 The battery can be damaged by pointed objects such as
nails or screwdrivers or by force applied externally. An
internal short circuit can occur and the battery can burn,
smoke, explode or overheat.
Product Description and Specifica-
tions
Read all safety warnings and all instruc-
tions. Failure to follow the warnings and in-
structions may result in electric shock, fire
and/or serious injury.
Technical Data
Article number
Rated voltage
No-load speed
– 1st gear
– 2nd gear
Impact frequency at no-load
Max. torque for hard/soft screwdriving applica-
tion according to ISO 5393
Max. drilling dia.
– Steel
– Wood
– Brickwork
Max. screw dia.
Chuck clamping range
Drill spindle thread
Weight according to EPTA-Procedure 01:2014
* depending on the battery pack being used
** limited performance at temperatures <0 °C
1 609 92A 1MX | (30.8.17)
Intended Use
The power tool is intended for driving and loosening screws
and for drilling in wood, metal, ceramic and plastic. The PSB
is additionally intended for impact drilling in brick, masonry
and stone.
The light of this power tool is intended to illuminate the power
tool's direct area of working operation and is not suitable for
household room illumination.
Product Features
The numbering of the product features refers to the illustra-
tion of the machine on the graphics page.
1 Keyless chuck
2 Torque presetting ring
3 Operating mode preselection ring
(PSB 18 LI-2 Ergonomic)
4 Gear selector
5 On/Off switch
6 Rotational direction switch
7 Battery unlocking button
8 Battery charge-control indicator
9 Battery pack*
10 "PowerLight"
11 Handle (insulated gripping surface)
*Accessories shown or described are not part of the standard de-
livery scope of the product. A complete overview of accessories
can be found in our accessories program.
Cordless Drill/Driver
PSR 18 LI-2 Ergonomic
3 603 JB0 1..
V=
-1
min 0 – 430
-1
min 0 – 1400
-1
min
Nm 32/28*
mm
mm
mm
mm
mm 1,5 – 13
1/2"
kg
Combination Cordless Drill
PSB 18 LI-2 Ergonomic
3 603 JB0 3..
18 18
0 – 430
0 – 1400
– 0 – 22500
32/28*
13 13
38 38
– 11
10 10
1,5 – 13
1/2"
1,2 1,3
