Technische Daten; Technical Data - Canton Reference 1.2 DC Bedienungsanleitung

Technische Daten

Reference 1.2 DC
Typ High-End-Standlautsprecher
Prinzip 3 1/2-Wege, Bassreflexsystem
Impedanz 4...8 Ohm
Nenn-/Musikbelastbarkkeit 500/900 Watt
SPL (1 W in 1 m) 89,5 dB
Übertragungsbereich 18...40.000 Hz
Übergangsfrequenz 180/400/2.800 Hz
Tieftonchassis 2 x 310 mm, Aluminium (Wave-Sicke)
Mitteltonchassis 2 x 180 mm, Aluminium
(TCC Technologie + Wave Sicke)
Hochtonchassis 25 mm, Alu-Keramik-Oxyd
Abmessungen 42 x 143 x 58,5 cm
Gewicht 96 kg
Gehäuseausführung Kirsch-Furnier „Piano-finish"
Abdeckung Stoffbespannung schwarz
Gehäuseausführung Lack schwarz „Piano-finish"
Abdeckung Stoffbespannung schwarz
Gehäuseausführung Lack weiß „Piano-finish"
Abdeckung Stoffbespannung schwarz
Besonderheiten DC-Technologie,
Vergoldetes Bi-Wiring/
Bi-Amping-Anschlussfeld mit
Pegelanpassung,
Integrierter Lautsprecherfuss
Reference 2.2 DC
Typ High-End-Standlautsprecher
Prinzip 3-Wege, Bassreflexsystem
Impedanz 4...8 Ohm
Nenn-/Musikbelastbarkkeit 400/700 Watt
SPL (1 W in 1 m) 89 dB
Übertragungsbereich 18...40.000 Hz
Übergangsfrequenz 200/2.800 Hz
Tieftonchassis 2 x 260 mm, Aluminium (Wave-Sicke)
Mitteltonchassis 180 mm, Aluminium
(TCC Technologie + Wave Sicke)
Hochtonchassis 25 mm, Alu-Keramik-Oxyd
Abmessungen 35 x 120 x 50,5 cm
Gewicht 60,5 kg
Gehäuseausführung Kirsch-Furnier „Piano-finish"
Abdeckung Stoffbespannung schwarz
Gehäuseausführung Lack schwarz „Piano-finish"
Abdeckung Stoffbespannung schwarz
Gehäuseausführung Lack weiß „Piano-finish"
Abdeckung Stoffbespannung schwarz
Besonderheiten DC-Technologie,
Vergoldetes Bi-Wiring/
Bi-Amping-Anschlussfeld mit
Pegelanpassung,
Integrierter Lautsprecherfuss

Technical data

Designed as
Engineering principle
Impedance
Nominal/Music Power Handling
SPL (1 W at 1 m)
Frequency Response
Crossover Frequency
Woofer
Midrange
Tweeter
Dimensions
Weight
Enclosure finish
Cover
Enclosure finish
Cover
Enclosure finish
Cover
Special features
Designed as
Engineering principle
Impedance
Nominal/Music Power Handling
SPL (1 W at 1 m)
Frequency Response
Crossover Frequency
Woofer
Midrange
Tweeter
Dimensions
Weight
Enclosure finish
Cover
Enclosure finish
Cover
Enclosure finish
Cover
Special features
Reference 1.2 DC
High-end-floorstanding speaker
3 1/2-way-bass reflex system
4...8 ohms
500/900 watts
89,5 dB
18...40.000 Hz
180/400/2.800 Hz
2 x 310 mm (12"), aluminum
2 x 180 mm (7"), aluminum
(TCC Technology + Wave Surround)
25 mm (1"), aluminum-ceramic-oxyd
16.5" x 56.3" x 22.9"
96 kg
Cherry veneer „Piano-finish"
Black fabric cover
Black lacquer „Piano-finish"
Black fabric cover
White lacquer „Piano-finish"
Black fabric cover
DC-technology
Gold-plated bi-wiring/
bi-amping connection field
integrated speaker base
Reference 2.2 DC
High-end-floorstanding speaker
3-way-bass reflex system
4...8 ohms
400/700 watts
89 dB
18...40.000 Hz
200/2.800 Hz
2 x 260 mm (10"), aluminum
180 mm (7"), aluminum
(TCC Technology + Wave Surround)
25 mm (1"), aluminum-ceramic-oxyd
13.7" x 47" x 19.9"
60,5 kg
Cherry veneer „Piano-finish"
Black fabric cover
Black lacquer „Piano-finish"
Black fabric cover
White lacquer „Piano-finish"
Black fabric cover
DC-technology
Gold-plated bi-wiring/
bi-amping connection field
integrated speaker base
