Installation
1
2
Open the glass panel and remove the aluminum grease filter. Mark the four holes
for the installation from the inside of the hood.
Take the hood back down again. Drill the four ø 8 mm holes at the marked
locations. Insert four wall plugs into the holes and four screws into the wall.
Hang the extractor hood back in the wall bracket and tighten the four screws on
the inside of the extractor hood.
Inner chimney
Chimney bracket
Outer chimney
Use 2x ST4 x 8-mm screws to connect the upper and lower shaft together. Before
attaching the bracket to the wells, measure and opt for a level of attachment.
