Fujitsu D2990 Handbuch Seite 5

D2990
External connectors rear
USB dual channel
1 = 5V USB
2 = 5V USB
1
3 = Data negative Port X
2
4 = Data negative Port Y
5 =
Fujitsu Technology Solutions
Power Supply
FAN1
Temp. Sensor
FAN2
Battery
PCIe16
LAN
PCIe1
PCIe1
Audio
USB
Frontpanel
8+9
DVI-D
Data positive Port X 10 = Not connected
CPU
LGA1155
Temp. Sensor
PCH
Buzzer
Desc Override
Enable
USB
4+5
6 = Data positive Port Y
7 = GND
8 = GND
9 = Key
Internal connectors and slots
SATA
0+1
SATA
4+5
Front panel
Reset
Power
Recovery
On/Off
Recovery inserted = The system starts
from USB stick and allows a BIOS recovery.
Details can be found in the BIOS manual.
A26361-D2990-Z330-1-8N19
HD-LED
1
2
Power LED
