The ambient temperature must always be between -5° C and +40° C. Keep away from direct insulation
(particularly in cars) and heaters.
The relative humidity must not exceed 50 % with an ambient temperature of 40° C.
This device must only be operated in an altitude between -20 and 2000 m over NN.
Never use the device during thunderstorms. Over voltage could destroy the device. Always disconnect the
device during thunderstorms.
- - -m
The symbol
between light-output and the illuminated surface must be more than 0.5 meters.
Always secure the device with a secondary attachment.
The maximum ambient temperature T
Operate the device only after having become familiarized with its functions. Do not permit operation by
persons not qualified for operating the device. Most damages are the result of unprofessional operation!
Never use solvents or aggressive detergents in order to clean the device! Rather use a soft and damp cloth.
Please use the original packaging if the device is to be transported. Make sure that you pack the device in
the original state.
Please consider that unauthorized modifications on the device are forbidden due to safety reasons!
If this device will be operated in any way different to the one described in this manual, the product may suffer
damages and the guarantee becomes void. Furthermore, any other operation may lead to dangers like short-
circuit, burns, electric shock, lamp explosion, crash etc.

DESCRIPTION OF THE DEVICE

Overview

Control Panel:
3
CTO IRIS
2
LAMP
ON/OFF
1
WHITE RED GREEN YELLOW

Features

Professional follow spot with a powerful 160 W LED
Suitable for a projection area of up to 20 meters
•
Comfortable control via control panel with buttons and faders
•
Color wheel with 5 different, dichroic color filters and white
•
Strobe effect with adjustable speed (1-20 flashes/sec.)
•
CTO correction filter 3200 K, 4500 K and 5600 K
•
Steplessly adjustable iris from 5-100%
•
Dimmer for stepless adjustment of the light-output brightness between 0 % and 100 %
•
Manual focus
•
Comfortable control via control-panel
•
Mounting bracket for installation on a stand
•
Equipped with one 160 W LED
•
Switch-mode power supply allows for automatic power supply adaption between 100 and 240 volts without
•
power selector
Power connection via Neutrik PowerCon socket and included power cable
•
determines the minimum distance from lighted objects. The minimum distance
= 40° C must never be exceeded.
a
5
4
DIMMER STROBE
6
(1) Color buttons
(2) Lamp On/Off
(3) CTO-fader: Convert-to-orange filter
(4) Iris-fader
(5) Dimmer-fader
(6) Strobe-fader: Includes strobe, pulse and random modes
BLUE ORANGE
