Playback Numeric Function : This selection of function defines the operation type of the NUMERIC
buttons of your remote control unit (RCU) while the 'Playbar' is displayed on the screen.
- Commercial Skip : When the NUMERIC buttons (1 to 9) are pressed the video will move forward
according to the NUMERIC buttons pressed. For example ; when '1' is pressed, 1min move forward,
'5' is pressed, 5min move forward from current position. When '0' is pressed, it will move back for
1minute.
- Percentage Move : When the NUMERIC buttons are pressed, the video will move to the location of
that % percentage of numbers pressed. For example ; if you press '10', you will move to the 10%
location of the total video length. If you press '99', you will move to the end of the video clip
recorded.
 TimeShift Device : You can select the TimeShift Device you wish to use.
- USB Network Drive.

Record Device : You can select the Recording device you wish to use.
- USB Network Drive.

2.2 Parental Control

User's access rights to a service and programs are controlled by
a 4-digit secret code that is defined by the user. Whenever you
attempt to access the parental control menu, a pop-up window
will ask you to input a PIN code. (If necessary, you can change
it.)
NOTE : The default PIN code is '0000'
 Censorship : Set the parental guidance rating of highlighted
censorship classification. The parental level is given as an age-
based number.
 Change Pin code : To change your PIN code, input the new
PIN code using the NUMERIC buttons. To verify the new PIN
code, input the new PIN code again.
 System : Set the access rights to the System menu.
 Installation : Set the access rights to the Installation menu.
 Configuration : Set the access rights to the Configuration menu.

Edit Service : Set the access rights to the Edit menu.
 Plugin : Plugin Set the access rights to the Plugin menu.

2.3 Display Setting


Info Box position : Set a position of the information window.
 Info Box Display Time : Set the time duration of the
information window being displayed on the screen after
changing services.

Info Box Event Type : Set the event type that display in left
bottom part of the information window.
- Present Event with Time :
Display the present event name with time. (Default)
- Present and Follow Event :
Display the present and following event name.

Volume Bar Display Time : Set the time duration of the
volume bar being displayed on the screen after changing audio volumes.
36
