Connecting the ARGUS
1
½
CAUTION
The device can become damaged.
Operation only possible with sinusoidal mains
voltages. Phase control dimmers or inverters with
3
square-wave or trapezoidal voltage curves will
damage the device.
|
Protect the ARGUS using a 16 A circuit breaker.
5
When switching inductive loads such as trans-
|
formers, relays, contactors or fluorescent lamps,
spikes occur which could lead to the load being
switched on again ("maintained light effect").
Connect a capacitor in parallel to the inductive
load to reduce these spikes.
The functional display lights up each time move-
|
ment is detected.
14 mm
Setting up the ARGUS manually
½
CAUTION
The device could become damaged.
The sensor head should only be rotated until it
reaches the stop and no further. To achieve an
angle "above" the stop, change the direction of
rotation.
1 Turn the controller A on the ARGUS to position A
(operation).
"Through-wiring" to other loads is permitted.
2 Align the sensor head in the direction of the area
that is to be monitored.
ARGUS permanently connected to the mains
The ARGUS constantly monitors its area
L
N
L N
Installation of the top section of the ARGUS
4° 29°
1
2
3 From its edge step into the area of detection to see
whether the ARGUS switches the load and the func-
tional display as required.
Setting the sensitivity
Here you can infinitely set the distance up to which AR-
GUS detects movements (any distance up to max.
3
16 m).
The ARGUS can now be put into operation.
Putting ARGUS into operation
Setting the brightness threshold
1 Connect the supply voltage.
Here you can infinitely set the ambient brightness level at
which the ARGUS detects movements and triggers a
The load is switched on for approx. 10 s or for the set pe-
switching procedure.
riod. The functional display lights up for approx. 10 s. Af-
ter that the ARGUS is ready for operation.
– Moon symbol (night operation): The ARGUS will only
detect movements during the hours of darkness (ap-
prox. 3 lux).
Conducting a functional test
– Sun symbol (day and night operation): The ARGUS
detects movements up to approx. 1000 lux.
The brightness sensor must not be covered up.
|
Setting the switching duration
Here you can set how long the loads connected to AR-
A
2
GUS are switched on for. When a movement is detected,
D
B
the load is switched on and stays switched on until the
1s
set period has elapsed. Every further movement restarts
C
the switching duration.
4
The ARGUS ignores the light-sensitive switch
|
=
once the load has been switched on. If the move-
ment detector does not switch the load off again,
the reason probably is that the ARGUS constant-
ly detects further movements and thus keeps re-
starting the switching duration.
Adopting the settings
The ARGUS has to adopt the adaptations of settings.
1 Turn the controller A to position D (adopt settings).
The function display blinks 1x for confirmation.
2 Turn the controller A back to position A (opera-
tion).
The ARGUS is now set and ready for operation.
Blocking out individual areas
Using the four segments supplied, you can block out un-
wanted zones and sources of interference from the area
of detection.
9°
Ensure that the brightness sensor A is not cov-
|
12°
12°
12°
12°
24°
ered, as the sensitivity to light is otherwise re-
duced.
Resetting the ARGUS
Reset to the factory settings
8,5° 8,5°
25°
Under certain circumstances, it may be neccessary to
reset this device to its factory settings and to reconfigure
it:
½
CAUTION
Malfunctions can occur!
When resetting to the factory settings, all the set-
tings and connections for this CONNECT device
are deleted. Maybe the radio system is not work-
ing any longer and must be reconfigured (See the
separate description of the CONNECT radio sys-
tem).
1 Turn the controller A on the ARGUS to position C
(reset).
2 After approx. 1 s the LED flashes short: The device
has now been reset to its factory settings.
3 Turn the controller A on the ARGUS back to posi-
tion A (operation).
Setting up the ARGUS via remote
control
Resetting to the factory settings
Under certain circumstances, it may be neccessary to
3 LUX
1000 LUX
reset this device to its factory settings and to reconfigure
it:
½
CAUTION
When you reset to the factory settings, all the set-
tings and connections for this device are deleted.
1 Turn the controller A on the ARGUS to position C
(reset).
40
80
40
80
3
3
20
20
2 After approx. 1 s the LED flashes short: The device
1s
8
1s
8
has now been reset to its factory settings.
min
min
1,2 sec
8 min 10 sec
3 Turn the controller A on the ARGUS back to posi-
tion A (operation).
|
Only 1 ARGUS can be taught per remote control!
AUTO
ON
OFF
SET
-30s
+30s
+
SET
merten
A Status LED (red, green)
B Setting: ARGUS operating mode
C Setting: Brightness
D Setting: Overshoot time
E Setting: Sensitivity
A
Activating the remote control
1
2
1 Remove the protective foil: The remote control is
ready to use immediately!
Teaching the ARGUS for use with remote control
The controller A must be set to position A(operation)
1
AUTO
ON
OFF
SET
AUTO
-30s
+30s
+
SET
3x
merten
The green LED starts flashing:
• LED flashes 3x per second: the remote control is al-
ready taught to an ARGUS and needs a reset.
• LED flashes 1x per second: the remote control is
ready for teaching.
2
A
„B"
D
C
3
=
10 s
4
„A"
D
B
15 s
C
You can use the remote control to adjust the AR-
|
GUS simply and conveniently during operation.
Setting the operating mode
Use the buttons to select one of the following statuses:
– Press the [ON] button: The local ARGUS is perma-
nently active, regardless of whether or not movement
is detected (permanent ON).
– Press the [OFF] button: The local ARGUS is perma-
nently switched off (permanent OFF).
– Press the [AUTO] button: .f the ARGUS is already on,
the overshoot time is started (automatic mode). Other-
wise the ARGUS remains off until a movement is de-
tected.
Setting the brightness threshold
– Press the [SET] button: the current brightness value is
adopted.
Setting the switching duration
A
– Press the [+30] or the [-30] button: the current over-
B
shoot time is reduced or increased by 30 s per push
C
of the button.
D
Setting the sensitivity
E
– Press the [SET] button: ARGUS flashes fast: Teach-
ing mode activated (controller F at the ARGUS at max-
imum). Then, run across the sensor range of the
ARGUS once within 30 s. The sensitivity of the AR-
GUS is set such that the measured movement is de-
tected. You can alter this value afterwards using the
[+] and [-] buttons.
With every adaptation of settings, no matter if on
|
the devicce by controller or by remote control, the
previous settings are overwritten.
Status LED
Red light
Remote control no longer connected to
ARGUS
Flashing red
Teaching mode activated
light
Green light
Remote control connected to ARGUS
How to change the battery
1
3
2
6s
Always insert the battery with the (+) pole facing
|
upwards.
Reset remote control
1 Press the [AUTO] button 3 times. The status LED
flashes green.
2 Hold down the [AUTO] button until the green status
LED goes out. The remote control has been
cleared.
Technical data
Remote control
Channels:
1
Radio frequency:
868 MHz
Range
Free field: up to 100 m
Indoors: up to 30 m
Battery:
1 lithium button cell (CR 2450N)
Display elements:
Status-LED
ARGUS
Nominal voltage:
AC 230 V ±10%, 50 Hz
Fuse:
Protect the ARGUS using a 16 A
circuit breaker.
Max. switching cur-
rent:
16 A, AC 230 V, cosϕ = 1
Nominal output
Incandescent
lamps:
AC 230 V, max. 2000 W
Halogen lamps:
AC 230 V, max. 1200 W
Fluorescent lamps: AC 230 V, max. 1200 W,
uncompensated
Capacitive load:
35 μF
Transformer load:
max. 600 VA
Power consumption: < 1 W
2
2
Connecting terminals: for 2x1.5 mm
or 2x2.5 mm
rig-
id conductor, stripped length
14 mm
External diameter of
one cable:
max. 14.5 mm
Angle of detection:
220°
Range:
max. 16 m
Number of levels:
7
Number of zones:
112 with 448 switching seg-
ments
Minimum mounting
1.7 m
height:
Recommended
mounting height:
2.5 m
Sensitivity:
infinitely adjustable
Light sensor:
infinitely adjustable externally,
from approx. 3 lux to approx.
1000 lux
Switching duration:
externally adjustable in 6 levels
of approx. 1 sec. to approx.
8 min.
Possible settings for
sensor head:
Wall mounting:
9° up, 24° down, 12° left/right, ±
12° axial
Ceiling mounting:
4° up, 29° down, 25° left/right, ±
8.5° axial
Type of protection:
IP 55 at an angle of inclination
from 15° to 90°
EC directives:
Low-voltage guideline
2006/95/EC
EMC directive 2004/108/EC
Schneider Electric GmbH c/o Merten
Gothaer Straße 29, 40880 Ratingen
www.merten.com
www.merten-austria.at
Customer care centre:
Phone: +49 2102 - 404 6000
