7 Technical Data

7 Technical Data
General
Display
View angle
Height of digits
Supply voltage
Current consumption
Power consumption
LCD reflective;
positively transflective; black digits; background illumination*
negatively transmissive; red digits; illumination*
2 rows, counter reading/presettings 5-digits
decimal point (up to 4 decimals)
12 o'clock
1st row 12,0 mm; 2nd row 6,0 mm
SELV: 12-30 VDC; protected against polarity reversal
SELV: 24 VAC, 50/60 Hz, ±10%
115/230 VAC, 50/60 Hz, ±10%
100-240 VAC; 50/60 Hz, ±10%
12 ... 30 VDC: < 200 mA,
24 VAC < 250 mA; including sensor supply
115/230 VAC, 50/60 Hz < 50 mA incl. sensor supply
100-240 VAC < 80 mA; incl. sensor supply at 90 VAC
< 5 W
< 8 W (switch-mode power supply)
152
