XG-C55X
Creation of correction value by straight-line
correction coefficient:
Number of image captures (when adjustment,
measurement):
Number of image captures (when teaching):
(2) Teaching
Basically only one time measurement is necessary for each model for teaching, however when the optical
characteristics, etc. of the set are greatly changed, set the conditions again and measurement is neces-
sary again according to the changes.
Measurement method of the correction coefficient
(1) Determines the standard set of C55. 1 unit (n units)
(2) Set settings are RGB mode INPUT 1.
(3) Execute teaching in the following condition setting in that standard set.
Condition setting
Model name:
Resolution:
Correction value X direction:
Correction value Y direction:
Correction bits number:
Minimum adjustment value:
Center adjustment value:
Maximum adjustment value:
Teaching number:
Teaching interval:
Brightness change direction by adjustment value: Brightness up with adjustment value + (checked)
Adjusting points:
Adjusting point (Test pattern display level)
Gradation 7:
Gradation 6:
Gradation 5:
Gradation 4:
Gradation 3:
Gradation 2:
Gradation 1:
Gradation 0:
Adjustment color:
(3) Color irregularity correction
Conditions setup
Correction procedure settings
Gradation 7:
Gradation 6:
Gradation 5:
Gradation 4:
Gradation 3:
91%
78%
65%
52%
40%
25%
13%
0%
Adjustment with WHITE (checked)
2. Lower-gradation correction value to be used.
0. Correction with correction coefficient.
0. Correction with correction coefficient.
0. Correction with correction coefficient.
1. Upper-gradation correction value to be used.
No (not checked)
2 times
4 times
Newly input the model name and optical characteris-
tics Var.
(Not related)
29
22
8
0
36
73
5
18
3-dimension (checked)
Gradation 4 (checked)
Gradation 5 (checked)
Gradation 6 (checked)
Do not check the gradations other than these.
