Sharp XG-C55X Serviceanleitung Seite 145

★
Ref. No. Part No.
DUNTKB929FE01
OUTPUT UNIT(Continued)
R1516 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide
R1519 VRS-CY1JF103FY J 10k 1/16W Metal Oxide
R1522 VRS-CY1JF000JY J 0
R1526 VRS-CY1JF000JY J 0
R1530 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R1531 VRS-CY1JF000JY J 0
R1532 VRS-CY1JF123FY J 12k 1/16W Metal Oxide
R1533 VRS-CY1JF103FY J 10k 1/16W Metal Oxide
R1534 VRS-CY1JF123FY J 12k 1/16W Metal Oxide
R1535 VRS-CY1JF123FY J 12k 1/16W Metal Oxide
R1537 VRS-CY1JF000JY J 0
R1538 VRS-CY1JF000JY J 0
R1539 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R1540 VRS-CY1JF103FY J 10k 1/16W Metal Oxide
R1541 VRS-CY1JF103FY J 10k 1/16W Metal Oxide
R1547 VRS-CY1JF182JY J 1.8k 1/16W Metal Oxide
R1548 VRS-CY1JF392JY J 3.9k 1/16W Metal Oxide
R1549 VRS-CY1JF332JY J 3.3k 1/16W Metal Oxide
R1550 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R1551 VRS-CY1JF822JY J 8.2k 1/16W Metal Oxide
R1552 VRS-CY1JF103JY J 10k 1/16W Metal Oxide
R1553 VRS-CY1JF000JY J 0
R2401 VRS-CY1JF000JY J 0
R2402 VRS-CY1JF000JY J 0
R2409 VRS-CY1JF000JY J 0
R2410 VRS-CY1JF103JY J 10k 1/16W Metal Oxide
R2411 VRS-TV1JD680JY J 68
R2412 VRS-CY1JF103JY J 10k 1/16W Metal Oxide
R2413 VRS-TV1JD680JY J 68
R2415 VRS-CY1JF103JY J 10k 1/16W Metal Oxide
R2416 VRS-TV1JD680JY J 68
R2417 VRS-CY1JF000JY J 0
R2418 VRS-CY1JF821JY J 820 1/16W Metal Oxide
R2440 VRS-CY1JF102JY J 1k
R2441 VRS-CY1JF102JY J 1k
R2442 VRS-CY1JF123JY J 12k 1/16W Metal Oxide
R2443 VRS-CY1JF471JY J 470 1/16W Metal Oxide
R2444 VRS-CY1JF470JY J 47
R2445 VRS-CY1JF333JY J 33k 1/16W Metal Oxide
R2446 VRS-CY1JF821JY J 820 1/16W Metal Oxide
R2447 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide
R2448 VRS-CY1JF392FY J 3.9k 1/16W Metal Oxide
R2449 VRS-CY1JF151FY J 150 1/16W Metal Oxide
R2450 VRS-CY1JF112FY J 1.1k 1/16W Metal Oxide
R2451 VRS-CY1JF100JY J 10
R2452 VRS-CY1JF183JY J 18k 1/16W Metal Oxide
R2456 VRS-CY1JF183JY J 18k 1/16W Metal Oxide
R2457 VRS-CY1JF183JY J 18k 1/16W Metal Oxide
R2458 VRS-CY1JF103JY J 10k 1/16W Metal Oxide
R2459 VRS-CY1JF103JY J 10k 1/16W Metal Oxide
R2460 VRS-CY1JF103JY J 10k 1/16W Metal Oxide
R2461 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R2462 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R2463 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R2464 VRS-CY1JF102JY J 1k
R2465 VRS-CY1JF102JY J 1k
R2466 VRS-CY1JF102JY J 1k
R2467 VRS-CY1JF102JY J 1k
R2602 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R2603 VRS-CY1JF103JY J 10k 1/16W Metal Oxide
R2604 VRS-CY1JF103JY J 10k 1/16W Metal Oxide
R2605 VRS-CY1JF100JY J 10
R2609 VRS-CY1JF104JY J 100k 1/16W Metal Oxide
R2611 VRS-CY1JF000JY J 0
R2612 VRS-CY1JF000JY J 0
R2614 VRS-CY1JF104JY J 100k 1/16W Metal Oxide
R2615 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R2616 VRS-CY1JF222JY J 2.2k 1/16W Metal Oxide
R2618 VRS-CY1JF104JY J 100k 1/16W Metal Oxide
R2620 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R2621 VRS-CY1JF104JY J 100k 1/16W Metal Oxide
Description Code
AA
AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
AA
1/16W Metal Oxide AA
AA
AA
AA
AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
AA
1/16W Metal Oxide AA
AA
1/16W Metal Oxide AA
AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
AA
AA
1/16W Metal Oxide AA
AA
AA
AA
AA
AA
AA
1/16W Metal Oxide AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
AA
AA
AA
1/16W Metal Oxide AA
AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
AA
AA
AA
AA
AA
AA
169
★
Ref. No. Part No.
R2622 VRS-CY1JF332JY J 3.3k 1/16W Metal Oxide
R2623 VRS-CY1JF182JY J 1.8k 1/16W Metal Oxide
R2625 VRS-CY1JF000JY J 0
R2626 VRS-CY1JF000JY J 0
R2628 VRS-CY1JF000JY J 0
R2629 VRS-CY1JF000JY J 0
R2631 VRS-CY1JF000JY J 0
R2632 VRS-CY1JF000JY J 0
R2635 VRS-CY1JF103FY J 10k 1/16W Metal Oxide
R2636 VRS-CY1JF103FY J 10k 1/16W Metal Oxide
R2637 VRS-CY1JF103FY J 10k 1/16W Metal Oxide
R2638 VRS-CY1JF103FY J 10k 1/16W Metal Oxide
R2639 VRS-CY1JF103FY J 10k 1/16W Metal Oxide
R2640 VRS-CY1JF682JY J 6.8k 1/16W Metal Oxide
R2641 VRS-CY1JF682JY J 6.8k 1/16W Metal Oxide
R2642 VRS-CY1JF103JY J 10k 1/16W Metal Oxide
R2643 VRS-CY1JF103JY J 10k 1/16W Metal Oxide
R2644 VRS-CY1JF103JY J 10k 1/16W Metal Oxide
R2645 VRS-CY1JF103JY J 10k 1/16W Metal Oxide
R2646 VRS-CY1JF103JY J 10k 1/16W Metal Oxide
R2647 VRS-CY1JF103JY J 10k 1/16W Metal Oxide
R2652 VRS-CY1JF103JY J 10k 1/16W Metal Oxide
R2701 VRS-CJ1JF101JY J 100 1/16W Metal Oxide
R2702 VRS-CY1JF000JY J 0
R2704 VRS-CY1JF103JY J 10k 1/16W Metal Oxide
R2705 VRS-CY1JF103JY J 10k 1/16W Metal Oxide
R2706 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R2707 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R2708 VRS-CJ1JF101JY J 100 1/16W Metal Oxide
R2711 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R2712 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R2713 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R2714 VRS-CY1JF103JY J 10k 1/16W Metal Oxide
R2715 VRS-CY1JF272JY J 2.7k 1/16W Metal Oxide
R2716 VRS-CJ1JF101JY J 100 1/16W Metal Oxide
R2718 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R2721 VRS-CY1JF473FY J 47k 1/16W Metal Oxide
R2723 VRS-CY1JF101JY J 100 1/16W Metal Oxide
R2724 VRS-CY1JF272JY J 2.7k 1/16W Metal Oxide
R2725 VRS-CY1JF103JY J 10k 1/16W Metal Oxide
R2726 VRS-CY1JF000JY J 0
R2751 VRS-CJ1JF101JY J 100 1/16W Metal Oxide
R2752 VRS-CY1JF000JY J 0
R2753 VRS-CY1JF103JY J 10k 1/16W Metal Oxide
R2754 VRS-CY1JF103FY J 10k 1/16W Metal Oxide
R2755 VRS-CY1JF272FY J 2.7k 1/16W Metal Oxide
R2756 VRS-CY1JF104JY J 100k 1/16W Metal Oxide
R2758 VRS-CE3AF1R0JY J 1
R2759 VRS-CY1JF222JY J 2.2k 1/16W Metal Oxide
R2760 VRS-CY1JF103JY J 10k 1/16W Metal Oxide
R2761 VRS-CY1JF000JY J 0
R2762 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide
R2763 VRS-CY1JF393JY J 39k 1/16W Metal Oxide
R2767 VRS-CY1JF103JY J 10k 1/16W Metal Oxide
R2770 VRS-CY1JF182JY J 1.8k 1/16W Metal Oxide
R2771 VRS-CY1JF392JY J 3.9k 1/16W Metal Oxide
R2772 VRS-CY1JF103JY J 10k 1/16W Metal Oxide
R2773 VRS-CY1JF102JY J 1k
R2774 VRS-CY1JF104JY J 100k 1/16W Metal Oxide
R4501 VRS-CY1JF105JY J 1M
R4503 VRS-CY1JF105JY J 1M
R4504 VRS-CY1JF470JY J 47
R4505 VRS-CY1JF102JY J 1k
R4506 VRS-CY1JF470JY J 47
R4507 VRS-CY1JF102JY J 1k
R4508 VRS-CY1JF000JY J 0
R4509 VRS-TV1JD000JY J 0
R4518 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide
R4519 VRS-CY1JF471JY J 470 1/16W Metal Oxide
R4520 VRS-CY1JF102JY J 1k
R4521 VRS-CY1JF222JY J 2.2k 1/16W Metal Oxide
R4522 VRS-CY1JF473JY J 47k 1/16W Metal Oxide
R4523 VRS-CY1JF224JY J 220k 1/16W Metal Oxide
R4524 VRS-CY1JF221JY J 220 1/16W Metal Oxide
R4542 VRS-CY1JF152JY J 1.5k 1/16W Metal Oxide
XG-C55X
Description Code
AA
AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
1/16W Metal Oxide AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
1/16W Metal Oxide AA
AA
1/16W Metal Oxide AA
AA
AA
AA
AA
1W Metal Oxide AC
AA
AA
1/16W Metal Oxide AA
AA
AA
AA
AA
AA
AA
1/16W Metal Oxide AA
AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
1/16W Metal Oxide AA
AA
AA
1/16W Metal Oxide AA
AA
AA
AA
AA
AA
