XG-C55X
Ref. No. Part No.
DUNTKB170DE04
INPUT UNIT(Continued)
FB3053 RBLN-0060TAZZY
FB3054 RBLN-0060TAZZY
FB3055 RBLN-0060TAZZY
FB3101 RBLN-0060TAZZY
FB3102 RBLN-0060TAZZY
FB3602 RBLN-0058CEZZY
FB3603 RBLN-0058CEZZY
FB3609 RBLN-0059CEZZY
FB5501 RBLN-0058CEZZY
J402 QSOCD0403GEZZ
J421 QJAKJ0008GEZZ
J431 QJAKG0064CEZZ
J441 QJAKJ0008GEZZ
J5501 QJAKJ0007TAZZ
SC3001 QSOCN0448FJZZ
SC3051 QSOCN0448FJZZ
SC3101 QSOCN0344FJZZ
SC3102 QCNCW3026TAZZ
SC3601 QSOCD0901CEZZ
SC3602 QCNCW2026TAZZ
★
Description Code
J Ferrite Bead AB
J Ferrite Bead AB
J Ferrite Bead AB
J Ferrite Bead AB
J Ferrite Bead AB
J Ferrite Bead AB
J Ferrite Bead AB
J Ferrite Bead AB
J Ferrite Bead AB
J Socket, Input 4 AE
J Jack, Audio IN1/2 AD
J Jack, Input 3 AG
J Jack, Audio Out AD
J Jack, Wired R/C In AC
J Socket, 17pin(Input4) AM
J Socket, 17pin(Input2) AM
J Socket, 17pin AM
(Output/Input1,2)
J Socket, 30pin(1A) AF
J RS-232C Terminal AH
J Socket, 20pin(1B) AE
Ref. No. Part No.
DUNTKB929FE01
OUTPUT UNIT
INTEGRATED CIRCUITS
IC302 VHiLV4053AT-1Y
IC303 VHiBA3530FS-1Y
IC1101 VHiL3E06100-1Q
IC1201 VHiL3E06100-1Q
IC1301 VHiL3E06100-1Q
IC1401 VHiL3E07070-1Q
IC1502 VHiNJM2904V-1Y
IC1505 VHiTC4W53U/-1Y
IC1506 VHiNJM2904V-1Y
IC2401 VHiSM5301AS-1Y
IC2402 VHiLMV7239+-1Y
IC2403 VHiLMV7239+-1Y
IC2404 VHiLV125AT+-1Y
IC2602 RH-iXA730WJZZQ
IC2603 VHiBD4729G+-1Y
IC2604 VHiSN2G32CT-1Y
IC2605 VHiHN24256T-1Y
IC2606 VHiSN2G53CT-1Y
IC2607 VHiAHCT08PW-1Y
IC2701 VHiM62320FP-1Y
IC2702 VHiM62320FP-1Y
IC2751 VHiM62392FP-1Y
IC2752 VHiPQ20WZ11-1Y
IC4502 VHiNJM2244M-1Y
IC4505 VHiBA7655AF-1Y
IC4506 VHiNJM2060V-1Y
IC4507 VHiTHC4538T-1Y
IC4508 VHiSNT1G08C-1Y
IC4510 VHiSNT1G08C-1Y
IC4511 VHiNJM2244M-1Y
IC7001 VHiPQ1R33//-1Y
IC7002 VHiPQ05DZ1U-1Y
IC7003 VHiPQ3DZ13U-1Y
IC7004 VHiPQ05DZ1U-1Y
IC7005 VHiPQ20WZ11-1Y
IC7006 VHiPQ018EZ5-1Y
IC7007 VHiT7MA541K-1Y
TRANSISTORS
Q301 VS2SA1530AR-1Y
Q302 VS2SD1760QA-1Y
Q303 VS2SD1760QA-1Y
Q304 VSHN2C01FU/-1Y
Q305 VSHN2C01FU/-1Y
Q306 VS2SC3928AR-1Y
Q307 VSDTC114EUA-1Y
Q308 VSDTC114EUA-1Y
Q1101 VS2SC3928AR-1Y
Q1102 VS2SA1530AR-1Y
Q1103 VS2SC3928AR-1Y
Q1104 VS2SA1530AR-1Y
Q1201 VS2SC3928AR-1Y
Q1202 VS2SA1530AR-1Y
Q1203 VS2SC3928AR-1Y
Q1204 VS2SA1530AR-1Y
Q1301 VS2SC3928AR-1Y
Q1302 VS2SA1530AR-1Y
Q1303 VS2SC3928AR-1Y
Q1304 VS2SA1530AR-1Y
Q1501 VS2SC3928AR-1Y
Q2401 VS2SC2735//-1Y
Q2402 VS2SC2735//-1Y
Q2403 VS2SC2735//-1Y
Q2415 VSHN1B04FU/-1Y
Q2416 VS2SC3928AR-1Y
Q2417 VS2SC3928AR-1Y
Q2418 VSDTC114EUA-1Y
Q2419 VSHN1C01FU/-1Y
Q2420 VSHN1C01FU/-1Y
Q2701 VSBSN20////-1Y
164
★
Description Code
J SN74LV4053APWR AE
J BA3530FS-E1 AM
J I.C BA
J I.C BA
J I.C BA
J I.C BB
J NJM2904V AF
J TC4W53FU AF
J NJM2904V AF
J SM5301AS-G-ET AR
J LMV7239M5X AH
J LMV7239M5X AH
J SN74LV125APWR AE
J IC AP
J BD4729G-TR AD
J SN74AHC2G32HDC AE
J HN58X24256TI AT
J SN74AHC2G53HDC AE
J SN74AHCT08PW AD
J M62320FP AH
J M62320FP AH
J M62392FP AM
J PQ20WZ1U AF
J NJM2244M AG
J BA7655AF AG
J NJM2060V AF
J TC74HC4538AFT AL
J SN74AHCT1G08DC AD
J SN74AHCT1G08DC AD
J NJM2244M AG
J PQ1R33 AE
J PQ05DZ1U AG
J PQ3DZ13U AG
J PQ05DZ1U AG
J PQ20WZ1U AF
J PQ018EZ5MZP AF
J TC7MA541FK AH
J 2SA1530AR AB
J 2SD1760QA AD
J 2SD1760QA AD
J HN2C01FU AC
J HN2C01FU AC
J 2SC3928AR AB
J DTC114EUA AB
J DTC114EUA AB
J 2SC3928AR AB
J 2SA1530AR AB
J 2SC3928AR AB
J 2SA1530AR AB
J 2SC3928AR AB
J 2SA1530AR AB
J 2SC3928AR AB
J 2SA1530AR AB
J 2SC3928AR AB
J 2SA1530AR AB
J 2SC3928AR AB
J 2SA1530AR AB
J 2SC3928AR AB
J 2SC2735 AB
J 2SC2735 AB
J 2SC2735 AB
J HN1B04FU AC
J 2SC3928AR AB
J 2SC3928AR AB
J DTC114EUA AB
J HN1C01FU AC
J HN1C01FU AC
J BSN20 AD
