XG-C55X
Ref. No. Part No.
CPCi-A002CE30
PC I/F UNIT(Continued)
SWITCH
SW80019DK001-70012
MISCELLANEOUS PARTS
FB8006 9DK001-81062
FB8013 9DK001-81062
FB8015 9DK001-81062
SC8001 9DK001-60078
SC8002 9DK001-60078
CASE8001 PSLDMA008WJFW J Shield Case
HOLD8001 LHLDW1021GE00
SHEET8001 PSPAZA061WJZZ
SHEET8002 PSPAZA061WJZZ
SHEET8003 PSPAGA134WJZZ
SHEET8004 PSPAGA134WJZZ
LABEL8001 9DK001-97078
NSFTZA001WJFW
★
Description Code
J Slide Switch, SSSS811101 AL
J Ferrite Bead, BLM21P221SG AE
J Ferrite Bead, BLM21P221SG AE
J Ferrite Bead, BLM21P221SG AE
J Connector, 82pin AQ
J Connector, 82pin AQ
AK
J Wire Holde AB
J Sheet AD
J Sheet AD
J Sheet
J Sheet
J Serial No. Label AD
J Shaft, x2 AD
Ref. No. Part No.
CABINET AND MECHANICAL PARTS
1 Not Available
1-1 DBDYRA005WJ01
1-1-1
Not Available
1-1-2 HiNDPA506WJSA
1-1-3 HiNDPA085WJZZ
1-1-4 HiNDPA516WJZZ
1-1-5 PSPAKA008WJ00
1-2 LX-HZ3106CEFD
1-3 LX-NZ3173CEFW
2
Not Available
2-1 DBDYTA036WJ01
2-1-1
Not Available
2-1-2 GCOVAA032WJKA J LED Cover, X2
2-1-3
Not Available
2-1-4 HiNDPA057WJSA
2-1-5 DBTN-A013WJ01
2-1-5-1 Not Available
2-1-5-2 HDECQA025WJKA J Decoration Button-A
2-1-5-3 HDECQA026WJKA J Decoration Button-B
2-1-5-4 HDECQA027WJKA J Decoration Button-C
2-1-7 PSPAZA106WJZZ
2-2 JBTN-A014WJKA
2-3 LANGKA006WJFW J Fixing Angle
2-4 MSPRCA001WJFW J Spring, for Height
2-5 PSPAT0013CEZZ
2-6 QCNW-A492WJZZ
2-7 XBPSF26P06000
2-8 XEBSD30P08000
2-9 XEPSD26P08000
3 Not Available
3-1 DBDYUA003WJ12
3-1-1 Not Available
3-1-2 HiNDPA505WJSA
3-1-3 HiNDPA292WJSA
3-1-4 HiNDPA114WJSB
3-1-5
Not Available
Security Connector
3-1-6 LX-NZ3120CEFW
3-1-7 LX-NZ3122CEFW
3-1-8 PFiLDA003WJZZ
3-2 DCOVAA029WJ01
3-2-1
Not Available
3-2-2 HPNC-A002WJSA
3-3 GCOVA1824CESA
3-4 GCOVAA030WJKA J Exhaust Panel
3-5 GCOVAA038WJKA J Handle Cover, x2
3-6 GLEGPA003WJKA
3-7 GLEGPA004WJKA
3-8 GLEGPA005WJKA
3-9 HPNC-A001WJSA
3-10 JHNDAA003WJZZ
3-11 LANGKA040WJFW J Anti-Theft Angle
3-12 LX-HZ3105CEFD
3-13 LX-NZ3095CEFD
3-14 LX-NZ3123CEFE
3-15 LX-NZ3173CEFW
3-16 LX-NZA003WJFW
3-17 PFiLDA002WJZZ
3-18 PSLDMA074WJZZ
3-19 PSPAH0648CE00
3-20 PSPAT0013CEZZ
3-21 PZETKA013WJZZ
3-22 PZETKA014WJZZ
3-23 PZETKA015WJZZ
3-24 QCNW-A493WJZZ
3-25 XBPSD30P08JS0
3-26 XBPSD40P05J00
178
★
Description Code
– Rear Body Unit Ass'y —
J Rear Body Ass'y AY
– Rear Body —
J Terminal Indication Panel AH
J Earth Label AD
J Lamp Replacement Label AE
J Spacer, x2 AD
J Screw, x1 AB
J Insert Nut, x1 AD
– Top Body Unit Ass'y —
J Top Body Ass'y BG
– Top Body —
BB
– "SHARP" Badge —
J "IQ" Label AF
J Operation Button Ass'y AX
– Operation Button —
AH
AH
AH
J Spacer, x4 AA
J Height Adjust Button AE
AD
AB
Adjust Button
J Tape, x4 AC
J Leaf Switch AH
J Screw, x1 AA
J Screw, x1 AA
J Screw, x1 AA
– Bottom Body Unit Ass'y —
J Bottom Body Ass'y BC
– Bottom Body —
J Model Label AL
J FCC Label AL
J Hot Caution Label AD
– Kensington Standard —
J Insert Nut(R) AB
J Insert Nut(L) AC
J PBS Filter AG
J Bottom Filter Cover Ass'y AR
– Bottom Filter Cover —
J Intake Punching Cover AL
J R/C Cover AD
AM
AF
J Adjuster Foot(Front) AW
J Adjuster Foot(Rear, Right) AH
J Adjuster Foot(Rear, Left) AH
J Punching Cover AL
J Carrying Handle BA
AD
J Screw, for Insert Nut, x1 AB
J Nut Screw(R) AA
J Nut Screw(L) AD
J Insert Nut, x1 AD
J Nut, x3 AD
J Filter AE
J Shield AK
J Spacer, x2 AB
J Tape, x2 AC
J Shield Spacer, x1 AG
J Shield Spacer, x1 AH
J Shield Spacer, x1 AD
J Leaf Switch AF
J Screw, x8 AA
J Screw, x3 AA
