Ref. No. Part No.
DUNTKB602DE01
KEY UNIT
TRANSISTORS
Q2201 VSDTC144EUA-1Y J DTC144EUA
Q2202 VSDTC144EUA-1Y J DTC144EUA
Q2203 VSDTC144EUA-1Y J DTC144EUA
Q2204 VSDTC144EUA-1Y J DTC144EUA
Q2205 VSDTC144EUA-1Y J DTC144EUA
DIODES
D2201 RH-PX0210TAZZY J LED, POWER
D2202 RH-PX0210TAZZY J LED, LAMP
D2203 RH-PX0210TAZZY J LED, TEMP
CAPACITORS
C2201 VCKYCY1EF104ZY J 0.1
C2202 VCKYTV1EF104ZY J 0.1
RESISTORS
R2201 VRS-CY1JF751FY J 750 1/16W Metal Oxide
R2208 VRS-CY1JF751FY J 750 1/16W Metal Oxide
R2210 VRS-CY1JF751FY J 750 1/16W Metal Oxide
R2211 VRS-CY1JF751FY J 750 1/16W Metal Oxide
R2213 VRS-TW2ED471JY J 470 1/4W
R2214 VRS-TW2ED122JY J 1.2k 1/4W
R2215 VRS-TW2ED471JY J 470 1/4W
R2216 VRS-TW2ED122JY J 1.2k 1/4W
R2217 VRS-TW2ED122JY J 1.2k 1/4W
R2218 VRS-CY1JF272FY J 2.7k 1/16W Metal Oxide
R2219 VRS-CY1JF272FY J 2.7k 1/16W Metal Oxide
R2220 VRS-CY1JF272FY J 2.7k 1/16W Metal Oxide
R2221 VRS-CY1JF472FY J 4.7k 1/16W Metal Oxide
R2222 VRS-CY1JF472FY J 4.7k 1/16W Metal Oxide
R2223 VRS-CY1JF472FY J 4.7k 1/16W Metal Oxide
R2224 VRS-CY1JF103FY J 10k 1/16W Metal Oxide
R2225 VRS-CY1JF103FY J 10k 1/16W Metal Oxide
SWITCHES
S2201 QSW-PA012WJZZY J Switch, ON
S2204 QSW-PA012WJZZY J Switch, MENU
S2205 QSW-PA012WJZZY J Switch, CURSOL Right/
S2206 QSW-PA012WJZZY J Switch, AUTO SYNC
S2207 QSW-PA012WJZZY J Switch, CURSOL DOWN
S2208 QSW-PA012WJZZY J Switch, ENTER
S2209 QSW-PA012WJZZY J Switch, KEYSTONE
S2210 QSW-PA012WJZZY J Switch, UNDO
S2211 QSW-PA012WJZZY J Switch, CURSOL LEFT/
S2212 QSW-PA012WJZZY J Switch, CURSOL UP
S2213 QSW-PA012WJZZY J Switch, OFF
S2214 QSW-PA012WJZZY J Switch, INPUT
MISCELLANEOUS PARTS
P2203 QPLGN0264TAZZY J Plug, 2pin(KY3)
SC2201 QSOCN1836TAZZY J Socket, 18pin(KY0)
Description Code
AB
AB
AB
AB
AB
AC
AC
AC
25V Ceramic AA
25V Ceramic AB
AA
AA
AA
AA
Metal Oxide AA
Metal Oxide AA
Metal Oxide AA
Metal Oxide AA
Metal Oxide AA
AA
AA
AA
AA
AA
AA
AA
AA
AD
AD
AD
VOL +
AD
AD
AD
AD
AD
AD
VOL -
AD
AD
AD
AC
AD
Ref. No. Part No.
DUNTKB603DE01
R/C RECEIVER UNIT
CAPACITORS
C5591 VCEASM0JW107MY J 100
C5592 VCKYCY1EF104ZY J 0.1
RESISTORS
R5591 VRS-CY1JF471JY
R5592 VRS-CY1JF220JY
MISCELLANEOUS PARTS
P5591 QPLGN0363TAZZY J Plug, 3pin(RC)
RMC5591 RRMCU0239CEZZ
171
XG-C55X
★
Description Code
6.3V Electrolytic AC
25V Ceramic AA
J 470 1/16W Metal Oxide AA
J 22 1/16W Metal Oxide AA
AC
J Remote Receiver AG
