Reloop JOCKEY IIIMaster Edition Bedienungsanleitung Seite 44

Element
T10
T11
T12
T13
T14
T15
T16
T17
T18
T19
T20
44
Funktion
Filter
Adjusts the filter effect for the active deck. In
zero position the filter is automatically turned
off.
Pan Dial
Herewith it is possible to adjust the volume
assignment for the left and right channel.
Zero position corresponds to an equal level on
both channels.
Pitchbend Button
Slows down the deck's pitch.
Pitchbend Button
Increases the deck's pitch.
Autoloop Function
Sets an automatic loop with the set loop length
(-T9-) without the need to manually set the
loop ending point.
Reloop Function
Jumps to the last set loop, reactivating it.
Beat Jump Backward
Executes a beat jump opposed to playback
direction.
Beat Jump Forward
Executes a beat jump in playback direction.
Hot Cue Delete Button
While this button is being pressed and held it is
possible to delete stored cue points by pres-
sing the corresponding Hot Cue Pads -T20-.
The LED corresponding to the respective Pad
will go out.
Hot Cue Bank Select
Selects the desired Hot Cue Bank. If the LED
is not lit, cue bank 1-4 is selected. Pressing the
button „5-8" allows the operation of Hot Cues
5-8 via the Hot Cue Buttons -T20-.
Hot Cue Buttons
Herewith it is possible to operate the 8 Hot
Cues of a track in Traktor. Depending on the
active bank (see -T19-), Hot Cues 1-4 or 5-8 can
be selected.
If a Hot Cue is unassigned (no LED feedback),
it is possible to assign it to the current track's
position by pressing one of the Pads -T20-.
Funktion bei aktivem Shift -T3-
FX Routing Button 1
Herewith it is possible to assign
FX Unit 1 to the current deck.
FX Routing Button 2
Herewith it is possible to assign
FX Unit 2 to the current deck.
Loop In/Set Cue Button
Manually sets a loop's starting
point. Simultaneously a cue point
will be defined.
Loop Out Button
Manually sets a loop's ending
point. Now the deck is in loop
mode; the set passage will now be
continuously repeated. Repressing
the button will end loop mode.
Left-Sided GRID Shift
Shifts the grid that Traktor puts
over the bass line a step to the
left.
Left-Sided GRID Shift
Shifts the grid that Traktor puts
over the bass line a step to the
left.
