1. DESIGN FEATURES

■ DIGITAL CAR AUDIO AMPLIFIER for a cross-over controlled amplification of satellite speaker
systems, kickwoofers and subwoofer systems
■ REMOTE LOWPASS LEVEL CONTROL to set the subwoofer volume level from the driver's seat
■ REGULATED MOSFET POWER SUPPLY to sustain very high output power into low impan-
dance loads
■ 1 OHM LOAD STABILITY to drive speaker systems with very low impedance, sustaining very
high power output levels
■ ELECTRONIC CROSSOVER with 12 dB/oct. or 18/24 dB/oct. slope steepness and fully varia-
ble cit-in / cut-off frequencies for highpass, bandpass or subsonic filtering of the individual channels
■ 2AWG POWER INPUT TERMINALS for direct connection of 35mm
main power wires
2
■ ADVANCED PROTECTION CIRCUITRY to safe-guard the amplifier from short-circuits at the
speaker outputs, DC offset voltage at the outputs and overheating of power electronics
■ ADJUSTABLE RCA INPUT SENSITIVITY from 200mV to 6V to provide a good match with the
line-output levels of almost any head-unit
■ EXTERNAL FUSES on the input side-panel, equipped with Maxi type fuse holders
