Instruction Manual K06-K09L
3.1. Explanation of the application range
Our mechanical crimping tools type K06-K09L are supplied with non interchangeable rotary
die discs (Pos. 1) to crimp non-insulated copper connectors 'Light Range'.
Table 1
Type Crimping range
K08L 16-95 mm²
K06L 10-120 mm²
K09L 25-150 mm²
Should it be necessary to crimp other connectors not mentioned in this chart please contact
the manufacturer.
Attention
Do not crimp on or use near live circuits. This tool is not insulated.
Before starting to crimp please make sure that all parts involved in the crimping process are
not energised.
Connectors
tubular cable lugs and connectors 'Light Range'
tubular cable lugs and connectors 'Light Range'
tubular cable lugs and connectors 'Light Range'
