Accessories; Technical Data; List Of Spare Parts Eh4 Basic - IKA EH 4 basic Betriebsanleitung

Accessories

EH 4.1
EH 4.2
EH 4.3

Technical data

(acc. DIN 12876)
design voltage:
or
design frequency:
class partitioning
acc. DIN 12876
identifying marking
acc. DIN 12876
heating power:
working temperature range:
temperature setting:
temperature constancy:
temperature control:
control sensor:
safety sensor:
safety temperature-
limitation adjustable:
pump type:
max. pump pressure:
max. flow of discharge:
min. bath depth:
min. effective depth:
permitted ambient
temperature:
permitted relative humidity:
12
Bath vessel
Bath vessel
Bath vessel
VAC 230±
10%
VAC 115±
10%
Hz 50/60
I
NFL
W 1500
°C 25 to 100
infinitely variable from
ambient temperatur
K ±0,12 by 70°C and 12 Ltr H O
2
two-step control
electro-mechanical
electro-mechanical
°C 25 to 200
pressure pump
bar 0,08 (0 litre flow of discharge)
l/min 5 (0 bar back pressure)
mm 160
mm 75
°C +5 to +40
% 80
permitted duration of operation: %
protection class acc. DIN 60529:
Fuses: 230V A
115V A
contamination level:
overvoltage category:
protection class:
Operation at a terrestrial altitude: m
dimensions: (W x D x H) mm 105 x 139 x 319
weight: kg

List of spare parts EH4 basic

Pos. Designation
1 Plastite-Counter sunk screw
3 Plastite-Cylinder head screw
6 Hexagonal nut
8 Disk
9 Snap ring
11 Connection line
12 Strain relief
13 Pilote lamp yellow
14 Pilote lamp red
15 Rocker switch
16 Clamp
17 Clamp
20 Safety capillary tube controller
21 Capillary tube controller
28 Motorholder
29 Bottom plate
30 Insolating disk
31 Pump holder
34 Protective tube
35 Tube heater body
100
IP 31
10AT Id.Nr. 27 554 00
15AT Id.Nr. 26 494 00
2
II
I (protective earth)
max. 2000 above sea level
2,3
Pos. Designation
36 Spacer piece
37 Suspension
38 Housing-lower part
39 Pump housing
40 Pump blade
41 Pump cover
42 Holding angle
43 BLP - power supply
44 Housing-upper part
45 Front panel
46 Operatin knob
47 Cap
54 Covering
60 Container clamp
2001Shaded pole motor,
compl.
5001Fuse
EH4b 1204
