Delta GSA ST700 ST750_Layout 1 16.10.15 11:20 Seite 1 Delta Gegenstromanlagen ST 700 / ST 750 Delta jet stream ST 700 / ST 750 Montage- und Betriebsanleitung Pflegetipps Installation- and operating instructions service instruction...
Seite 2
Delta GSA ST700 ST750_Layout 1 16.10.15 11:20 Seite 2 Montage und Betriebsanleitung: Die Durchführungen sind mit beiliegendem Bauschutz so abzudecken, dass sämtliche Ge- windeteile geschützt sind. Der Einlauftopf muss ca. 250 mm unter dem Wasserspiegel angebracht werden. Beide Einbautöpfe sind bündig zur Beckeninnenseite anzubringen (ev. Isolierung beachten) Der ufstellungsort der Pumpe ist so zu wählen, dass sie sich möglichst nahe an den Durch- führungen befindet.
Seite 3
Die Pumpe darf niemals trockenlaufen (d.h. ohne Wasser), da ansonsten die Gleitringdich- tung beschädigt wird (Garantieverlust). Die Benutzung in und an Schwimmbecken bzw. Gartenteichen ist nur zulässig, wenn diese nach den lokalen gesetzlichen Bestimmungen errichtet sind. Kontaktieren Sie diesbezüglich Ihren NEPTUN-Fachmann bzw. die lokale Baubehörde.
Delta GSA ST700 ST750_Layout 1 16.10.15 11:20 Seite 4 Technische Daten der Pumpen: Basiseinheit ST 700 ST 750 ST 770 Spannung 230V/50Hz 3~230/400/50Hz. bgabe/ ufnahme in KW 1,6 / 2 2,1 / 2,6 2,6 / 3 Fördermenge l/min max. Strömung nach 2m in m/sec * 1,5 Stromaufnahme siehe Pumpen-Typenschild Vorsicherung...
Seite 5
Delta GSA ST700 ST750_Layout 1 16.10.15 11:20 Seite 5 installation- and operating instructions: To protect all the threaded parts, you have to cover the implementations with the enclosed, self-adhesive building protection. The run-pot must be fixed approximately 250 mm below the water surface. Both built-in pots must be mounted flush to the inside of the pool (note a possible isolation) The site of the pump must be chosen as close as possible to the implementations.
Seite 6
(which means without water), because otherwise the mechanical seal will be damaged (loss of warranty). The use in and around swimming pools or garden ponds is only permitted if they are built according to local statutory regulations. In this regard please contact your Neptun expert or the local bulding department.
Seite 7
Delta GSA ST700 ST750_Layout 1 16.10.15 11:20 Seite 7 technical data of pumps: base unit ST 700 ST 750 ST 770 voltage 230V/50Hz 3~230/400/50Hz. emission / admission in kW 1,6 / 2 2,1 / 2,6 2,6 / 3 maximum flow rate l / min. max. flow after 2 m in m / sec.
Seite 8
Delta GSA ST700 ST750_Layout 1 16.10.15 11:20 Seite 8 Packungsinhalt: Delta Gegenstromanlage ST 750 / 770 package contents: Delta jet stream ST 750 / 770 Packungsinhalt: Delta Gegenstromanlage ST 700 package contents: Delta jet stream ST 700...
Seite 11
Delta GSA ST700 ST750_Layout 1 16.10.15 11:20 Seite 11 Notizen / Notes...
Seite 12
Delta GSA ST700 ST750_Layout 1 16.10.15 11:20 Seite 12 Ihr Neptun Fachhändler: Your Neptun specialist supplier: www.neptun-int. om Version 20150313 ten. Druck- und Satzfehler vorbehalten. Kein nspruch auf Vollständigkeit. Technische Änderungen vorbehal Printing errors and error rate reserved. No demanding on completeness. Technical changes reserved.
