Input Level
Active ANT Power
Bandwidth
Demodulation
Transmission mode(FFT)
Constellations
Guard intervals
Code rate
Scattered Pilot Pattern
DVB-T2 Input Profiles
POWER SUPPLY
Input Voltage
Power Consumption
MPEG TS A/V Decoding
Transport Stream
Input Rate
Aspect Radio
Video Decoding
Video Resolution
Audio Decoding
Audio Mode
Version vom 12. September 2014
-82.0dBm and -20.0dBm
DC 5V at max 75 mA, Overload protection
VHF/UHF: 6MHz, 7MHz, 8MHz
COFDM
1k, 2k, 4k, 8k normal and extended, 16k normal and extended, 32k
normal and extended.
QPSK, 16-QAM, 64-QAM, 256-QAM
Both rotated and non-rotated
1/4, 19/256, 1/8, 19/128, 1/16, 1/32, 1/128
DVB-T: Viterbi + Reed Solomon 1/2, 2/3, 3/4, 5/6, 7/8.
DVB-T2: LPDC + BCH 1/2, 3/5, 2/3, 3/4, 5/6.
PP1, PP2, PP3, PP4, PP5, PP6, PP7, PP8
Input Mode A-Signal PLP, input Mode B-Multiple PLPs(Common
PLP, Type 1 and 2 up to the maximum allowed figure 255)
Free Voltage (100~240V AC, 50/60Hz)
20W MAX
MPEG-2, H.264
Max.120Mbit/s
4:3, 16:9, Letter Box
MPEG-2, MP@ML, MPEG-4 part 10/H264
720*480P/I, 720*576P/I, 1280*720p,1920*1080i, 1920*1080P
MEPG-1 layer I/II, Mpeg2 layerII, Dolby digital
Left / Right / Stereo/ Mono
Seite 43
