►Specifications

SYSTEM RESOURCES
Main Processor
Flash Memory
DDR SDRAM
Tuner/Front-end(Optional)
Tuner Type
Input Connector
Signal Level
LNB Power & Polarization
22KHz Tone
DiSEqC Control
Demodulation
Input Symbol Rate
Forward Error Correction
(FEC)
Tuner Type
Input Connector
Frequency Range
Version vom 12. September 2014
594MHz based CPU
16 Mbyte
256 Mbyte
DVB-S / DVB-S2
F-type, Connector, Female
-65 to -25 dBm
Vertical: +13V
Horizontal: +18V
Current: Max. 400mA
Overload Protection
Frequency: 22±1KHz
Amplitude: 0.6±0.2V
Version 1.0, 1.1 1.2, USALS Available, Unicable
QPSK, 8PSK
1-45 Mbps, Convolution Code Rate
DVB-S 1/2, 2/3, 3/4 5/6, 7/8
DVB-S2 1/2, 3/5 , 2/3, 3/4 ,4/5 , 5/6, 8/9 , 9/10
DVB-T2/T/C
IEC-type, Connector, Female
47MHz~862MHz
