Dimensions of dTLS luminaire in mm
dTLS 85 luminaire
dTLS 85 luminaire with
compensating capacitor box
L218 mounting stirrup
X = fixing dimensions
Explosion protected light fittings
Type: dHLS 85250, dHLS 85400 and dTLS 85250
1

Technical data

1.1 dHLS 85250; 85400 luminaire
Apparatus marking to 94/9/EC:
Explosion protection:
EC type examination certificate:
Luminaire
Compensation box
Rated voltage:
Rated current:
HME 250W (
mercury vapour high-pressure lamp
HME 400W (
mercury vapour high-pressure lamp
HIE 250W (
metal vapour high-pressure lamp
HSE 250W (
sodium vapour high-pressure lamp
HSE 400W (
sodium vapour high-pressure lamp
Incandescent lamp 150 W
Power factor: ϕ 250 W
ϕ 400 W
Perm.ambient temperature in original packing:
Permissible ambient temperature:
Other temperatures possible with special versions.
Degree of protection to EN 60529/IEC 529:
Insulation class to EN 60598/IEC 598:
Cable entries (KLE) (standard version): 2xM25
Terminals:
Test torques:
Pressure screw of KLE M25 for min. cable Ø
Pressure screw of KLE M25 for max. cable Ø
Terminals
Cover screws
Material:
Housing colour:
Weight (standard version):
Illuminant:
1 . 2 dTLS 85 luminaire
Apparatus marking to 94/9/EC:
Explosion protection:
EC type examination certificate:
Luminaire
Compensation box
Rated voltage:
Rated current:
with diffuser 250 W
with parabolic reflector 250 W
Power factor ϕ 250 W
Perm.ambient temperature in original packing:
Permissible ambient temperature:
Other temperatures possible with special versions.
Degree of protection to EN 60529/IEC 529:
Insulation class to EN 60598/IEC 598:
Cable entries (KLE) (standard version): 2xM25
Terminals:
Test torques:
Pressure screw of KLE M25 for min. cable Ø
Pressure screw of KLE M25 for max. cable Ø
Terminals
Cover screws
Material:
Housing colour:
Weight (standard version):
Illuminant:
II 2 G
EEx de II C T3
DMT 03 ATEX E 039
BVS 03 ATEX E 106X
230 V +6 / - 10 %, 50 / 60Hz
Type induct.
) 85250 2.20A
) 85400 3.25A
) 85250 3.00A
) 85250 3.00A
) 85400 4.40A
85150
0.5
0.6
-50° C up to +80° C
-20° C up to +40° C (standard version)
IP65 (standard version)
I - is complied with by the luminaires
1x Ø 8 -17mm, 1x screwed plug
each terminal 2 x 1.5 - 2.5 mm² (L+N+PE)
5.0 Nm
3.5 Nm
2.5 Nm
5,5 Nm
housing Cast light metal with special paint
bezel ring Grey cast iron with special paint
Grey (RAL 7032)
approx. 30.0 kg (without compensation box)
approx. 37.0 kg (with compensation box)
to 400W HME - Mercury vapour high-pressure lamp
to 250W HSE - Sodium vapour high-pressure lamp
to 250W HIE - Metal vapour high-pressure lamp
to 150W Incandescent lamp
II 2 G
EEx de II C T3
DMT 03 ATEX E 039
BVS 03 ATEX E 106X
230 V +6 / - 10 %, 50 / 60Hz
Type induct.
85250S 3.00A
85250P 3.00A
0.4
-50° C up to +80° C
-20° C up to +40° C (standard version)
IP65 (standard version)
I - is complied with by the luminaires
1x Ø 8 -17mm, 1x screwed plug
each terminal 2 x 1.5 - 2.5 mm² (L+N+PE)
5.0 Nm
3.5 Nm
2.5 Nm
5,5 Nm
housing Cast light metal with special paint
bezel ring Grey cast iron with special paint
Grey (RAL 7032)
approx. 25.0 kg (without compensation box)
approx. 32.0 kg (with compensation box)
to 250W HIT-DE - Metal vapour high-pressure lamp
to 150W HST-DE - Sodium vapour high-pressure lamp
