UP/DN-Buttons on the microphone
To skip to the next channel press the UP-button. If you keep pressing this button the "auto-repeat"
function is obtained.
To skip to the last channel, press the DN-button. If you keep this button the "auto-repeat" function is
obtained.
Note!
If the channel will not change make sure that the "EMG" button has not been pressed. In this case, press
the "EMG" button to deactivate this function. As far as other functions are concerned refer to previous
instructions.
TO RECEIVE
Turn on the power by rotating VOLUME clockwise. Set Squelch control to maximum counterclockwise
position. Set channel selector to the desired channel. Adjust Squelch to cut out annoying background
noise when no signal is received.
TO TRANSMIT
Press the push to talk button on the microphone and hold it at an angle of about 5-7,5 cm to your mouth
and speak in a normal voice. To receive again release the push to talk button.
Be sure the mic plug is firmly connected to the jack, for if the connector becomes loose, you may end
with squeal, feedback and other problems.
SCAN button
With this control, you can automatically seek for a busy channel.
• Turn the Squelch clockwise until the background noise is no longer heard.
• Press the ''SCAN'' button: the transceiver will scan automatically all the channels until a carrier is
being received.
• When it finds a carrier it stops and starts again some seconds after the ending of the communication
on the channel.
When the radio is transmitting, the scan function is deactivated.

Dual Watch

This function allows the synchronisation on two different channels at the same time. Thanks to this
function, you can monitor a second channel. When a signal on the second channel is received, the
conversation on the first channel is automatically interrupted and the receiver switches to the second
channel. The monitoring starts again 8 seconds after the signal ends/stops.
To activate this function, operate as follows:
• Select the desired channel using the channel selector
• Press the "DW" button
• Select the second channel
• Press the button "DW" again
To cancel the function press again the "DW" button or the PTT button.
Note!
If after activating the DW-function no other action is carried out for 8 sec. the transceiver is set into
normal transmit mode.
5

SPECIFICATIONS

GENERAL
Channels ....................................................................................................................................... 40 FM
Frequency Range ................................................................................................ 27.965 to 27.405 MHz
Frequency Control ............................................................................................................................ PLL
Operating Temperature Range ..................................................................................... -10
DC input voltage ............................................................................................................ 13.8V DC
Size ......................................................................................................... 150 (L) x 40 (H) x 170 (P)mm
Weight ...................................................................................................................................... 0,950 Kg
RECEIVER
Receiving system .......................................................................... Dual conversion superheterodyne
Intermediate frequency ................................................................................................. I
.......................................................................................................................................... II
Sensitivity ..................................................................................... 0.5
Audio output power @10% THD .................................................................................. 2.O W @ 8 Ohm
Audio distortion ................................................................................................. Less than 8% @ 1KHz
Image rejection .............................................................................................................................. 65dB
Adjacent channel rejection ............................................................................................................. 65dB
Signal/Noise ratio ........................................................................................................................... 45dB
Current drain at stand/by ............................................................................................................. 250mA
TRANSMITTER
Output power .......................................................................................................... 4W FM @ 13.8V DC
Modulation ........................................................................................................... FM:1,8KHz
Frequency response .......................................................................................... from 400Hz to 2.5KHz
Output impedance ........................................................................................... RF 50 Ohm unbalanced
Signal/Noise Ratio .................................................................................................................40 dB MIN
Current drain .............................................................. 1100mA (Power position with no modulation)
All specifications are subject to change without notice.
Approval:
The ALAN 235 ESP E40 is exempt from registration and charges. The licensing marks include among
others the letters CEPT PR 27 and can also originate from other European countries. You may use the
ALAN 235 ESP E40 in Germany and for instance when travelling (almost) everywhere in Europe with-
out formatlities free of charge.
°
C to +55
°
IF:10.695 MHz
°
IF:455 KHz
µ
V for 10 dB SINAD in FM mode
±
6
°
C
±
15%
0,2KHz
