Energetics CT 210 HEIMTRAINER Betriebshandbuch Seite 6

Part list
Part Description
1 Main frame
2 Front stabilizer
3 Rear stabilizer
4 Seat support
5 Handlebar post
6 Handlebar
7 Rear foot cap
8 Front foot cap
9 Foot roller
10 Square neck bolt M8*75L
11 Domed nut M8*1.25*15L
12 Seat
13 Flat washer M8
14 Nut M8
15 Spring knob
16 Inner tube
17 Foam 530L
18 Round cap D7/8''*17L
19 Flat washerD28*D8.5*D3T
20 Allen Bolt M8*20L
21 Spring washer D15.4*D8.2*2T
22 Curved washer D22*D8.5*1.5T
23 Computer ST8324
24 Upper computer cable
25 Lower computer cable
26 Upper tension cable
27 Handle pulse
Handle pulse cable
28 Protective cover
29 Bushing
30 Spring washer D15.4*D8.2*2T
31 Flat washer D16*D8.5*1.2T
32 T-shaped knob
33 Bearing #99502
34 Lower tension cable
35 Screw M5*10L
36 Belt wheel
Qty Part Description
1 37L Left crank
1 37R Right crank
1 38 Magnetic
1 39 Anti-loosen Nut M6
1 40 Bolt M6*15L
1 41 Sea washer D21*D16* 0.3T
2 42 Flat washer D24*D16*1.5T
2 43 C-shaped ring
2 44 Bolt M8*25L
4 45 Screw cap D23*6.5
4 46 Flat washer D50*D10*1.0T
1 47 Spacer (small)
3 48 Flat washer D30*D10*3.2T
3 49 Idle wheel fixing plate
1 50 Nut D9.5x5T(3/8"-26UNF)
1 51 Club knob
2 52 Spring
2 53 Idle wheel
1 54 Anti-loosen Nut M10
4 55 Flat washer D21*D10.5*2T
8 56 Magnetic system
8 57 Rubber ring
1 58L Left chain cover
1 58R Right chain cover
1 59L Left decorative cover
1 59R Right decorative cover
2 60 Pedal set
L/R
2 61 Screw ST4.2x1.4x20L
1 62 Screw ST4*10L
1 63 Axle crank
1 64 Belt
1 65 Spacer
1 66 Oval cap
2 67 Seat adjustable tube
1 68 Flat washer D50*D10*2.0T
1 69 Plastic cover
1
6
Qty
1
1
1
4
4
2
1
1
2
2
2
2
1
1
2
1
1
1
2
1
1
1
1
1
1
1
1
8
2
1
1
1
2
1
1
2
