Installation - HQ Power VDP700SM Bedienungsanleitung

• Select a location where the device is protected against extreme heat (see "Technical Specifications"), dust and
moisture. Ensure a minimum distance of 0.5m between the device and any nearby surface or passer-by.
• Use an appropriate safety cable to fix the device (e.g. VDLSC7 or VDLSC8).
• Familiarise yourself with the functions of the device before actually using it. Do not allow operation by unqualified
people. Any damage that may occur will most probably be due to unprofessional use of the device.
• Use the original packaging if the device is to be transported.
• All modifications of the device are forbidden for safety reasons.
• Only use the device for its intended purpose. Other uses may lead to short circuits, burns, electroshocks etc.
Using the device in an unauthorised way will void the warranty.

4. Installation

No. / Nr.
1
2
3
4
5
6
7
8
9
10
a) Smoke Liquid
• Please use non-inflammable water-based smoke fluid without oil or grease, such as VDLSL1 (1 litre), VDLSL5 (5
litres), or VDLSL5H (5 litres high density smoke liquid).
• Non-recommended smoke liquid may damage the machine and void the warranty.
1. Unplug the device from the mains.
2. Unscrew the cap from the tank.
3. Carefully pour smoke liquid into the tank, keeping the level below the "Full" mark at the back.
4. Reposition the cap on the tank.
Remark: Do not operate the device when the tank is open.
VDP700SM_v3
ENGLISH
nozzle
housing
mounting bracket
tightening screw
washer
tank cap
230V-plug
fuse holder
power cord
remote control
NEDERLANDS
mondstuk
behuizing
montagebeugel
bevestigingsschroef
dichtingsring
dop van de tank
230V-plug
zekeringhouder
voedingskabel
afstandsbediening
4
FRANCAIS
embout
boîtier
support de montage
écrou de fixation
rondelle
bouchon du réservoir
fiche 230V
porte-fusible
cordon secteur
télécommande
