DMX-Protocol

48-Channel mode:

Channel: Value:
1 000-255
2 000-255
3
000-255
4 000-255
5 000-255
6 000-255
. .
. .
. .
46
000-255
47 000-255
48 000-255

CLEANING AND MAINTENANCE

We recommend a frequent cleaning of the device. Please use a soft lint-free and moistened cloth. Never use
alcohol or solvents!
There are no serviceable parts inside the device except for the fuse. Maintenance and service operations are
only to be carried out by authorized dealers.

Replacing the fuse

If the fine-wire fuse of the device fuses, only replace the fuse by a fuse of same type and rating.
Before replacing the fuse, unplug mains lead.
Procedure:
Step 1: Open the fuse-holder on the rear panel with a fitting screwdriver.
Step 2: Remove the old fuse from the fuse-holder.
Step 3: Install the new fuse in the fuse-holder.
Step 4: Replace the fuse-holder in the housing.
Should you need any spare parts, please use genuine parts.
If the power supply cable of this device becomes damaged, it has to be replaced by a special power supply
cable available at your dealer.
Should you have further questions, please contact your dealer.
Function:
Red 1 ( 0 – 100 %)
Green 1 ( 0 – 100 %)
Blue 1 ( 0 – 100 %)
Red 2
Green 2
Blue 2
.
.
.
DANGER TO LIFE!
Disconnect from mains before starting maintenance operation!
( 0 – 100 %)
( 0 – 100 %)
( 0 – 100 %)
Red 16 0 – 100%)
(
Green 16 ( 0 – 100 %)
Blue 16 ( 0 – 100 %)
23/24 00084271, Version 1.1
