PIXEL 1
Color mode:
1 Red
2 Green
3 Blue
4 Yellow
5 Purple
6 Cyan
7 White
8
R
9 B
10 Gr
11 R
12 W
13
off
14
B
15 Gr
Internal programs/Speed
Here you can set internal programs and cycle speed.
Press the MODE button until the display shows "Pr--".
Select the desired internal program (Pr-1 – Pr-7) via the UP or DOWN button. (See following graphic).
Pr.-1 Seven color dreaming
Pr.-2 Seven color flow
Pr.-3 Seven color flow in one direction
Pr.-4 Seven color flow in the opposite direction
Pr.-5 Seven color flow in two directions
Pr.-6 Seven color relay in one direction
Pr.-7 Seven color relay in the opposite direction
In order to set the desired speed of the internal program, press the ENTER button until the display shows
"SP.-".
(0 - 7, increasing)
The desired speed
Please press the MODE button to attain the main menu.
Auto Mode/Speed
In Auto Mode, the each internal program is called up alternatingly in a continuous loop.
Press the MODE button until the display shows "AU--".
The desired speed of the continuous loop (0 – 7, increasing) can be selected via the UP or DOWN buttons.
Please press the MODE button to attain the main menu.

Sound Control Mode

Press the MODE button and choose Sound Controlled Mode „Soud".
The ENTER, UP and DOWN buttons have no function in this mode.
Please press the MODE button to attain the main menu.

Master/Slave Mode

Press the MODE button to select the SLAVE mode: „SLAu". The devices set in this manner can now be
controlled by the master unit.
The ENTER, UP and DOWN buttons have no function in this mode.
Please press the MODE button to attain the main menu.
2 3 4 5
R R R R
Gr Gr Gr Gr
B B B B
Y Y Y Y
P P P P
C C C C
W W W W
Gr R Gr R
R B R B
Gr P P Gr
R B B R
off W off W
R off R off
B B b B
Gr Gr Gr Gr
can be set via the
6 7 8 9
R R R R
Gr Gr Gr Gr
B B B B
Y Y Y Y
P P P P
C C C C
W W W W
Gr R Gr R
R B R B
Gr P P Gr
R B B R
off W off W
R off R off
B B B R
Gr Gr Gr P
UP or DOWN buttons
21/24
10 11 12 13
R R R R
Gr Gr Gr Gr
B B B B
Y Y Y Y
P P P P
C C C C
W W W W
Gr R Gr R
R B R B
Gr P P Gr
R B B R
off W off W
R off R off
R R R R
P P P P
00084271, Version 1.1
14 15 16
R R R
Gr Gr Gr
B B B
Y Y Y
P P P
C C C
W W W
Gr R Gr
R B R
Gr P P
R B B
off W off
R off R
R R R
P P P
