Cable Pin
Brown Live
Blue Neutral
Yellow/Green Earth
The earth has to be connected!
If the device will be directly connected with the local power supply network, a disconnection switch with a
minimum opening of 3 mm at every pole has to be included in the permanent electrical installation.
The device must only be connected with an electric installation carried out in compliance with the IEC-
standards. The electric installation must be equipped with a Residual Current Device (RCD) with a maximum
fault current of 30 mA.
Lighting effects must not be connected to dimming-packs.

Connection between devices

On the rear panel, there is an IEC socket (Power Out). Connect the output with the input of the next fixture
until all fixtures are connected.
Please note: A maximum of 8 EUROLITE LED PT- DMX Pixel Tube devices may be linked together. After
every 8 devices, the fixtures must have a renewed connection with the power mains.

OPERATION

After you connected the LED PT- DMX Pixel Tube to the mains, it starts running.
The LED display lights up and you can choose the desired mode via the buttons MODE, ENTER, UP and
DOWN.
The device has two operating modes. It can be operated in Stand Alone mode via LED display with
operating buttons or in DMX-controlled mode via a lighting controller.

- STAND ALONE-MODE

• Static colors
• Internal programs/speed
• Auto/speed
• Sound control
• Master/Slave
• White balance
- DMX MODE
STAND ALONE-MODE
Static colors
Setting colors:
Here you can set the desired static colors and color combinations.
Press the MODE button until the display shows "CO--". You can now select from 15 preset colors and color
combinations via the UP or DOWN button (C001 – C015). (See following graphic).
Please press the MODE button to attain the main menu.
International
L
N
20/24 00084271, Version 1.1
