Addressing
Each device occupies 2 channels. To ensure that the control signals are properly directed to each device,
the device requires addressing. This is to be adjusted for every single device by changing the DIP-switches
as set out in the table below.
The starting address is defined as the first channel from which the device will respond to the controller.
Please make sure that you do not have any overlapping channels in order to control each device correctly
and independently from any other fixture on the DMX data link. If two, three or more devices are addressed
similarly, they will work similarly.
Occupation of the DIP-switches:
Controlling:
After having addressed the device, you may now start operating these via your controller.
DMX-protocol
Channel 1 - Dimmer
Value
000-255
Brightness, increasing
Channel 2 - Strobe
Value
000-004
Static light
005-249
Strobe speed, increasing, 8Hz - 8Hz (46-480 flashes/min)
250-255
Microphone sensitivity
Function
Function
15/16
00082002.DOC, Version 1.1
