RFC 4800 Gebrauchsanleitung
RFC 4800 Instructions for Use
3. Elektrische Daten / electrical data
Versorgungsspannung / Supply Voltage:
RFC 48xx xxx 1xx xxx:
RFC 48xx xxx 2xx xxx:
RFC 48xx xxx 3xx xxx: 12/24 VDC ( 9...34 VDC)
Stromaufnahme / current draw:
Serie / Series 600: typ. 15 mA
Serie / Series 700: typ. 30 mA
Litzen/ wires:
AWG 20 / 0,5mm
2
Kabel/ cable:
Geschirmte bzw.
ungeschirmte Leitung
AWG 26 / 0,14mm
Shielded or unshielded cable
with lead wires
AWG 26 / 0,14mm
ACHTUNG ! Bei Verlängerung des geschirmten Kabels
ist auf ausreichende Schirmdämpfung zu achten !
3.1 Ausgangssignal / Output Signal
Serie / Series 600 single
4. Montagehinweise
Es sind bei der Montage ausschließlich die mitgelieferten
Linsenflanschkopfschrauben zu verwenden. Bei der Montage ist
das maximale Anzugsmoment von 250 Ncm zu beachten.
Falls vorhanden, ist der Kabelschirm an Masse anzuschliessen.
Der Mindest-Biegeradius des Kabels beträgt 40mm. Ein
dauernder Zug auf das Anschlusskabel in jeglicher Richtung ist
zu vermeiden.
Wenn das Kabel im Gebrauch bewegt wird, muss das Kabel
durch geeignete Maßnahmen (Schelle o.ä.) nach dem Austritt
fixiert werden.
Artikelnummer: 517009_07
24 VDC ( 18...30 VDC)
5 VDC ( 4,5...5,5 VDC)
Signal
Versorgung 1
Supply 1
Masse 1
Ground 1
Signalausgang 1
2
Output Signal 1
Versorgung 2
Supply 2
2
Masse 2
Ground 2
Signalausgang 2
Output Signal 2
Änderungen vorbehalten / subject of change
Elektrische Anschlüsse / Electrical Connections
Aderabgang /
lead wire output
Serie 600
Serie 700
Serie 700
Model 600
Model 700
Model 700
single
part. red.
fully red.
Rot
Rot
Rot
RD red
RD red
RD red
Schwarz
Schwarz
Schwarz
BK black
BK black
BK black
blau
blau
blau
BL blue
BL blue
BL blue
-
-
Rot/Weiss
RD/WH
red/white
-
-
Schwarz/Weiss
BK/WH
black/white
-
blau / Weiss
blau/Weiss
BL/WH
BL/WH
blue /white
blue /white
CAUTION ! Extension of shielded cable demands a
sufficient shielding !
Serie / Series 700 partly / fully redundant
4. Installation Instructions
Only the the delivered button head socket screws with flange
are to be used. Pay attention to the maximum tightening torque
of 250 Ncm when fastening.
If existing, connect the cable shield to GND.
Minimum bending radius of the cable is 40mm. Avoid steady
tension on the cable in any direction.
If the cable is moving in the application, appropriate action is to
be taken to fix the cable after the outlet of the sensor (use of
fixation clamp or similar).
Kabelabgang /
cable output
Serie 600
Serie 700
Model 600
Model 700
single
part. red.
Grün
Grün
GN green
GN green
Braun
Braun
BN brown
BN brown
weiss
weiss
WH white
WH white
-
-
-
-
-
Gelb
YE
yellow
Seite/ Page 2
