will do. We strongly recommend you to avoid the
Fig. 9 Fig. 10
use of any kind of solvents, alcohol or abrasive
products on the visor. It is recommended to
replace the visor when scratches or marks appear
during the use; they can impair your view.
Replacing the visor.
Disassembly:
Place the helmet on a solid and flat surface and
completely open the visor; pull the lever as it is shown by the red arrow (Fig. 9) until it reaches
its maximum displacement and take out the visor from the mechanism (Fig. 10); first take out the
geared part and then the circular zone. Repeat the same sequence on the other side.
Assembling:
Place the visor over the helmet in the position that it will have, as it would be in completely open
position. Hold the part of the visor slotting into the visor mechanisms over them. Pull the lever as it
is shown by the red arrow until it reaches its maximum displacement and insert the visor in its place,
when doing this introduce first the circular zone in its place and then introduce the geared part.
Release the lever. Open and close the visor several times to make sure it has been well assembled.
DETACHABLE COMFORT PADDING
Your helmet is equipped with detachable comfort padding. You can wash the comfort padding. To
clean the padding, once disassembled, it is recommended to wash it by hand with neutral soap and
let it dry without exposing it to the sun.
- 12 -
