About the interface cards
Input current
if set to Low Range and Default Level = L
U = 0V
in
U = 1V
in
U = 4V
in
if set to Low Range and Default Level = H
U = 0V
in
U = 1V
in
U = 4V
in
if set to High Range and Default Level = L
U = 0V
in
U = 1V
in
U = 4V
in
if set to High Range and Default Level = H
U = 0V
in
U = 1V
in
U = 4V
in
Response time
1)
IF- G1 (GPIB)
Terminals
Bus standard
Cable length (GPIB)
Cable type (GPIB)
IF-E1 / IF-E2 (Ethernet)
Terminals
Cable type (Ethernet)
Protocols
Used ports (Ethernet)
Network connection
Transmission speed Ethernet
Transmission speed USB
1 Time between occurance of an event, that has to be signalised to an
output, and the moment it is signalised.
© 009, Elektro-Automatik GmbH & Co. KG
4pole Centronics socket (female)
IEEE 488.1/
m per device, 0m total
Standard GPIB cable
1x RJ45 (LAN / WAN)
1x USB, type A
Twisted pair, patch cable,
Cat 3 or higher
VXI11, HTTP
80, 111, 00, 65
10/100 MBit
100 kBaud
57600 Baud

3. Installation

0mA

3.1 After unpacking

+.6mA
After unpacking, check the pluggable interface card(s) for
+5mA
signs of physical damage. If any damage can be found do
not use and insert the card into any device!
-1.5mA
+.mA

3.2 Inserting a card

+6mA
The card(s) must only be inserted while the unit is completely
switched off. The unit does not have to be opened. Remove
0mA
the screws from the slot cover or from an already equipped
+1.6mA
card and remove the cover/card. Insert the new card with
+3.5mA
caution until the card plate touches the rear side of the unit.
If there is space between the rear side and the card pla-
-1.5mA
te, do not tighten the screws, because the card is not
+0.7mA
placed correctly! The wiring between the PC and/or other
+4.5mA
units has also be done before the unit is switched on again.
< 10ms
The card(s) will be automatically detected by the device after
powering it on and can now be configured.
Note about the IF-A1: before equipping the card, you should
set the jumpers correctly. Refer to „4.4.1 Configuring the IF-
A1", subsection „Digital inputs".
Note: in case the card is not recognized after switching the
unit on, it might be necessary to update the firmware of your
device. Please contact your dealer for further information.
Caution! There are components on the card which are
sensitive for ESD. You must follow the general ESD provi-
sions when handling and installing a card.

3.3 Combining interface cards

At models with more than one card slot following restrictions
apply:
- never equip two cards of the same type
- the cards IF-R1 and IF-U1 must not be equipped together
- IF-G1 must not be combined with IF-C1 or IF-E1
- IF-E1 must not be combined with IF-C1, IF-G1, IF-R1 or
IF-U1

4. Details about the cards

The interface cards are designed to be used in various type of
device series. Depending on the typical features of a certain
device type, like for example an electronic load, the resulting
operability will change. This section handles the configuration
and handling of the cards by example of the PSI 9000 series.
But there are specific characteristics at other device series
which are explained farther below.
Information about the handling and navigation in the menus
and parameter pages of the various device types is available
the corresponding user manuals.
