Overview

This manual is an expansion of the "user manual". You must comply with all instructions and
safety information in the user manual!
Install the charging station according to the "installation manual".
1.1

Status LED

Status LED
Flashes slowly blue
every 3 sec-
onds
Lights up con- blue
tinuously
Segment 1 lights up orange
Overview
Status LED - segments
The status LED provides information about the current
operating state of the charging station. It consists of 4
segments (S1 to S4), which can light up or flash, to-
gether or individually, in various colors.
The status LED is only visible when the power is
switched on.
If not otherwise specified, all 4 segments light up to-
gether.
Function
Authorization is required (charging station was not authorized correctly;
authorization with RFID, key switch or external enable required)
External enable still required (authorization with RFID or key switch car-
ried out; vehicle connected correctly; external enable on the enable input
still required)
RFID programming mode (RFID cards can be programmed in this mode.
For details, see Chapter
[15]".)
"↪ 2.2 Programming RFID cards (optional)
