7. Feed carriage bolts through the other bracket
and the base of the saw as before. Ensure both
brackets are parallel to each other.
8. To place the saw onto the stand, grasp and
lift saw by mounting bracket assembly by the
release levers. These levers do not lock the saw
laterally in place but merely serve as a means of
mounting the saw to the beam.
9. Approach the beam with saw/bracket assembly
tilting toward your body slightly. Engage the
concave front lip of the mounting bracket with
rounded edge of beam. One of the brackets
must engage the locator clip (i) to prohibit lateral
movement of the saw during use.
10. When front edge of the beam and locking
locator clip are engaged, a slight downward
pivot will allow secure engagement of the
release levers to the back of the beam. Rock
the saw gently on the brackets to verify locking
in position.
11. Adjust the saw position as necessary to have
the blade perpendicular to the beam when in
the 0 degree mitre position.
12. Tighten the four nuts holding the saw to the
brackets securely.
DE7025 Universal Mitre Saw
Mounting Method (fi g. 1, 7–9)
WARNING: To reduce the risk of
injury, turn unit off, disconnect
machine from power source before
assembling the mitre saw to the
mitre saw stand. An accidental start-
up can cause injury.
WARNING: Stability Hazard. You must
use the plywood mounting method
described in the following instructions
when mounting a mitre saw not
manufactured by D
saw stand.
WARNING: To reduce the risk of
personal injury, be sure the mitre saw is
fully anchored on the stand.
WARNING: For your own safety,
read and understand the mitre saw
instruction manual before using. Failure
to heed these warnings may result in
personal injury and serious damage to
the mitre saw and the accessory.
NOTE: If you do not have a D
must use 19 mm plywood to mount your mitre saw.
The plywood must be a minimum of 101.6 mm
wider than the the largest width of the mitre saw
base. The plywood should be at least as deep
as the smallest depth of the mitre saw base or a
minimum of 406.4 mm if mitre saw base is smaller.
Ensure the plywood is square.
1. Once the plywood size has been determined,
2. Place DE7025 mounting brackets on the stand:
3. When the front edge of beam and locator clip
4. Place plywood onto mounting brackets and
5. Use 13 mm wrench to tighten hardware.
6. The mitre saw should be mounted to the
WALT to this mitre
E
Carry Strap
WALT mitre saw, you
E
If you purchase the carry strap accessory for
D
E
end to mount the accessory.
drill 9.5 mm holes 25.5 mm from the front
corners of the plywood, 355 mm apart and
25.5 mm from the sides.
a. Grasp and squeeze release levers (g).
b. Engage the concave front lip of the mounting
bracket with rounded front edge of beam.
One of the mounting brackets must be
engaged in the locator clip (i) to prohibit
lateral movement of the saw during use.
are engaged, a slight downward pivot will allow
secure engagement of the release levers to the
back of the beam. Follow same procedure with
second mounting bracket at the appropriate
position on the beam for the size of the
plywood.
align drilled holes with slots in mounting
brackets. Refer to DE7025 Hardware
Selection Chart and use either Method 1 or 2
to secure plywood to mounting brackets.
plywood using holes in the mitre saw base. The
hardware size will be determined by the holes
in the mitre saw base. Hardware should be
31.8 mm longer than the maximum height of
the mitre saw base at each mounting location.
a. Transfer location of mounting holes from
mitre saw base to plywood.
b. Drill holes according to the size of the
hardware chosen. NOTE: Hardware must
be purchased to mount mitre saw to
plywood. All purchased hardware should be
a minimum of Grade 5 or Class 8.8.
c. Secure mitre saw to plywood as shown in
Figure 9. Saw base (p), 19 mm plywood (t),
flat washer (q), lock washer (s) and nut (r).
NOTE: Ensure a flat washer (q) is used
between plywood (t) and lock washer (s).
d. Tighten all hardware.
WALT stands, use the square hole in the metal
EN G LI SH
21
