VISUAL TruView Installations- Und Einrichtungsanleitung Seite 9

sudo /usr/sbin/system-config-appliance -i
10.1.1.2 -m 255.255.255.0 -g 10.1.1.1
Follow on-screen instructions to complete the configuration.
5
Verify the network settings. Enter the following:
6
sudo /sbin/ifconfig eth0
From a remote PC, open the Remote Desktop Connection
7
application.
Enter the configured IP address of the Visual TruView server and
8
click Connect.
Enter the username and password. Then, click OK.
9
The default username is vuptime. The default password is
Visual1.
Set the Windows date, time, and time zone. Select the time zone
10
where the Visual TruView server is located. Double-click the
Windows clock in the notification area to open it.
If the Windows clock is not there, right-click Start, and select
Properties. Select the Taskbar tab and enable Show the
Clock.
Close the Remote Desktop application.
11
From a remote PC open a Web browser and enter the configured
12
IP address of the Visual TruView server followed by :8000/
tvadmin.
For example: http://192.168.0.100:8000/tvadmin
The TruView Appliance System Administration Login screen is
displayed.
Enter the username and password. Then, click
13
The default username is TVadmin. The default password is tv.
Click
14
TruView server is located and click
The services will restart. Click Continue.
Under Time Server (NTP Server), manually configure the IP
15
address of an NTP time server and click
NTP Services will restart. Click Continue.
Click Return to Appliance.
16
Click
17
6
Date/Time. Select the time zone where the Visual
Network Settings.
.
.
.
