Install
Follow the instructions in the Rack Mounting Kit (supplied) to install
1
the Visual TruView server into a cabinet.
Connect the server to the power supply.
2
Follow the instructions in the Wire Management Kit (supplied) to
3
organize and protect cables.
Setup
You can use a laptop PC or a USB keyboard, USB mouse, and monitor
to configure the Visual TruView server.
The configuration sequence involves setting the IP address of the Visual
TruView server, setting the Windows date/time zone on the server,
and setting the date/time for the Visual TruView application. This
insures that data collected by the Visual TruView application is
synchronized.
Laptop PC Setup
Turn on the laptop.
1
Select Start > Control Panel > Network Connections >
2
Local Area Connection.
The sequence listed above is for Windows XP. Refer to the
manufacturer's documentation for other operating systems.
Click Properties.
3
Select Internet Protocol (TCP/IP) and click Properties.
4
Click Use the following IP address.
5
Set the laptop's IP address and IP address parameters.
6
The laptop's IP address must be in the same subnet
(192.168.0.0) as the default IP address (192.168.0.100) of
the Visual TruView server. It is suggested that you use
192.168.0.99 as the laptop's IP address.
Use an Ethernet cable to connect the laptop to the Gb1 port on the
7
rear panel.
Power on the Visual TruView server.
8
On the laptop, do the following:
9
