If desired, change the hostname of the appliance. Click
18
the New hostname box, enter a name and click
Set an IP address for the primary and for the secondary DNS
19
server. Click
Configure the management port's IP address settings. Click
20
On the Network Interface screen, configure the address
settings (static IP is highly recommended). Then, click
Close the Web browser.
21
Use an ethernet cable and connect the Gb1port of the Visual
22
TruView server to your network switch.
Confirm Network Connectivity
From a remote computer, select Start > Programs >
1
Accessories > Command Prompt.
Run a PING test to verify IP connectivity to the Visual TruView
2
server. At the command prompt, enter the following:
ping xxx.xxx.xxx.xxx
where
xxx.xxx.xxx.xxx
server.
If the PING test succeeds, the Visual TruView server has an active
connection to the network. If the PING test fails, try the following:
•
Check the physical connection to the Visual TruView server.
•
Check that firewalls and access lists are updated to allow
traffic to and from the Visual TruView server's IP address.
•
Run the Tracert utility to the router to find out more about the
hop where connectivity failed.
If you cannot fix the problem, contact your network administrator.
Connect the Test Interfaces
The Visual TruView server has two test interface ports (labeled 1 and
2) on the rear panel of the data acquisition card.
•
The 1G Visual TruView server has a copper SFP module inserted
into each of test interfaces.
•
The 10G Visual TruView server has a fiber SFP+ module inserted
in each of the test interfaces.
Connect the output of a switch SPAN, mirror port, or Test Access Port
(TAP) to each Visual TruView test interface in succession. Verify that the
link indicator LED on the Visual TruView data acquisition card is
illuminated.
.
.
is the IP address of the Visual TruView
. In
.
.
