VISUAL TruView Installations- Und Einrichtungsanleitung Seite 8

On the remote PC, open a Web browser and enter the configured
15
IP address of the Visual TruView server followed by :8000/
tvadmin.
For example: http://10.1.1.2:8000/tvadmin
The TruView Appliance System Administration Login screen is
displayed.
Enter the username and password. Then, click
16
The default username is TVadmin. The default password is tv.
Select the Appliance tab.
17
Click
18
TruView server is located and click
The services will restart. Click Continue.
Under Time Server (NTP Server), manually configure the IP
19
address of an NTP time server and click
NTP Services will restart. Click Continue.
Click Return to Appliance.
20
Then, click System Halt / Reboot.
21
Click Reboot System.
22
Close the web browser.
23
The Visual TruView server is now configured.
24
USB Keyboard, USB Mouse, and Monitor Setup
Connect a USB keyboard, USB mouse, and monitor to the Visual
1
TruView server.
Power on the Visual TruView server.
2
Log in to the Visual TruView server.
3
The default username is TVadmin. The default password
is tv.
Configure the network settings. Edit the ifcfg-eth0 file as follows:
4
sudu su -
vi /etc/sysconfig/network-scripts/ifcfg-eth0
Edit the IPADDR line to add the IP address of the TruView
appliance.
Edit the NETMASK line and
The command to configure the Visual TruView server as shown is:
Date/Time. Select the time zone where the Visual
.
.
.
5
