Argo SDIA Installationshandbuch
DECLARATION OF CONFORMITY
This product is marked
– Low voltage no. 2006/95/EC. (Standard: EN60335-2-40:2003 (incl. Corr.:2006) + A11:2004 + A12:2005 + A13:2012
+ A1:2006 + A2:2009 con EN 60335-1:2002 + A11:2004 + A1:2004 + A12:2006 + A2:2006 + A13:2008 + A14:2010 +
A15:2011).
– Electromagnetic compatibility no. 2004/108/EC, 92/31 EEC and 93/68 EEC. (Standard: EN55014-1 (2006) + A1(2009)
+ A2(2011), EN 55014-2 (1997) + A1(2001) + A2 (2008), EN 61000-3-2 (2006) + A1(2009) + A2(2009),
EN 61000-3-3 (2008)
– RoHS2 no.2011/65/EU.
– Regulation (EU) no. 206/2012, of 6 march 2012, concerning the specifications for ecodesign requirements of air
conditioners and fans.
– Regulation (EU) no. 626/2011, of 4 may 2011, concerning the labeling indicating the energy consumption of air
conditioners.
This declaration will become void in case of misuse and/or non observance though partial of manufacturer's installation
and/or operating instructions.
L
Cooling Maximum conditions
Outdoor temperature :
Room temperature :
L
Cooling Minimum conditions
Outdoor temperature :
Room temperature :
Tools required for installation (not supplied)
1.Standard screwdriver
2.Phillips head screwdriver
3.Knife or wire stripper
4.Tape measure
5.Level
6.Sabre saw or key hole saw
7.Hacksaw
8. Core bits ø 8
INSTALLATION INSTRUCTIONS
as it satisfies Directives:
OPERATING LIMITS
43°C D.B.
32°C D.B. / 23°C W.B.
–15°C D.B.
10°C D.B. / 6°C W.B.
19.Hammer
10.Drill
11. Tube cutter
12.Tube flaring tool
13.Torque wrench
14.Adjustable wrench
15.Reamer (for reburring)
16.Hex. key
37.4255.041.05
- Split system air conditioner -
L
Heating Maximum conditions
Outdoor temperature :
Room temperature :
L
Heating Minimum conditions
Outdoor temperature :
Room temperature :
Model Combinations:
SEE CATALOGUE
Power Supply:
220 - 240 V ~ 50 Hz
REGULATION (EU) No. 517/2014 - F-GAS
The unit contains R410A, a fluorinated greenhouse gas with
a global warming potential (GWP) of 2087.50. Do not
release R410A into the atmosphere.
11/2014
24°C D.B. / 18°C W.B.
27°C D.B.
–15°C D.B.
5°C D.B.
EG
I
F
D
E
P
GR
Inhaltsverzeichnis
Verwandte Anleitungen für Argo SDIA
Inhaltszusammenfassung für Argo SDIA
- Seite 1 INSTALLATION INSTRUCTIONS - Split system air conditioner - DECLARATION OF CONFORMITY This product is marked as it satisfies Directives: – Low voltage no. 2006/95/EC. (Standard: EN60335-2-40:2003 (incl. Corr.:2006) + A11:2004 + A12:2005 + A13:2012 + A1:2006 + A2:2009 con EN 60335-1:2002 + A11:2004 + A1:2004 + A12:2006 + A2:2006 + A13:2008 + A14:2010 + A15:2011).
- Seite 2 IMPORTANT! • Ground the unit following local electrical codes. • The Yellow/Green wire cannot be used for any connection Please read before installation different from the ground connection. • Connect all wiring tightly. Loose wiring may cause This air conditioning system meets strict safety and operating overheating at connection points and a possible fire standards.
- Seite 3 Deoxidized annealed copper tube for refrigerant tubing connecting the units of the system; it has to be insulated with foamed polyethylene (min. thickness 8mm). MODEL NARROW TUBE LARGE TUBE OUTER DIAMETER MIN. THICKNESS OUTER DIAMETER MIN. THICKNESS SDIA 6,35 mm 0,8 mm 9,52 mm 0,8 mm 6,35 mm 0,8 mm 0,8 mm SDIB 12,7 mm PVC pipe for condensate drain pipe (ø...
-
Seite 5: Istruzioni Di Installazione
ISTRUZIONI DI INSTALLAZIONE - Condizionatore d’aria Split System - DICHIARAZIONE DI CONFORMITÀ Questo prodotto è marcato in quanto conforme alle Direttive: – Bassa Tensione n. 2006/95/CE (Standard: EN60335-2-40:2003 (incl. Corr.:2006) + A11:2004 + A12:2005 + A13:2012 + A1:2006 + A2:2009 with EN 60335-1:2002 + A11:2004 + A1:2004 + A12:2006 + A2:2006 + A13:2008 + A14:2010 + A15:2011). - Seite 6 IMPORTANTE! • Eseguire la messa a terra dell’unità secondo le norme elettriche locali. Leggere prima di iniziare l’installazione • Il conduttore giallo/verde non può essere utilizzato per collegamenti diversi dalla messa a terra. Questo sistema di condizionamento deve seguire rigidi •...
- Seite 7 Tubo in rame ricotto e disossidato per refrigerazione per il collegamento tra le unità e isolato con polietilene espanso di spessore min. 8 mm. MODELLO TUBO PICCOLO TUBO GRANDE DIAMETRO ESTERNO SPESSORE MINIMO DIAMETRO ESTERNO SPESSORE MINIMO SDIA 6,35 mm 0,8 mm 9,52 mm 0,8 mm 6,35 mm 0,8 mm 0,8 mm SDIB 12,7 mm Tubo in PVC per scarico condensa (ø...
-
Seite 9: Notice D'installation
NOTICE D’INSTALLATION - Climatiseur split - DECLARATION DE CONFORMITÉ Ce produit est marqué puisque il est conforme aux Directives: – Basse Tension n° 2006/95/CE. (Standard: EN60335-2-40:2003 (incl. Corr.:2006) + A11:2004 + A12:2005 + A13:2012 + A1:2006 + A2:2009 with EN 60335-1:2002 + A11:2004 + A1:2004 + A12:2006 + A2:2006 + A13:2008 + A14:2010 + A15:2011). - Seite 10 IMPORTANT! • Effectuez la mise à la terre de l'appareil en respectant les réglementations électriques locales. Veuillez lire ce qui suit avant de commencer • Le câble jaune/vert ne peut en aucun cas être utilisé pour Ce système de conditionnement de l'air répond à des toute autre connexion que celle de la mise à...
- Seite 11 Lignes en cuivre recuit et désoxydé pour réfrigération pour le raccordement entre les unités. La ligne doit être isolée en mousse de polyéthylène avec épaisseur min. de 8mm. MODELE PETIT TUBE GROS TUBE DIAMETRE EXTERIEUR EPAISSEUR MIN. DIAMETRE EXTERIEUR EPAISSEUR MIN. SDIA 6,35 mm 0,8 mm 9,52 mm 0,8 mm 6,35 mm 0,8 mm 0,8 mm SDIB 12,7 mm Tube en PVC pour sortie du condensat (Ø...
- Seite 13 INSTALLATIONSANLEITUNGEN - Zweirohrsystem-Klimaanlage - KONFORMITÄTSERKLÄRUNG Dieses Produkt ist mit -Zeichen gekennzeichnet, weil es den folgenden Richtlinien entspricht: – Niederspannungsrichtilinie 2006/95/EG. (Standard: EN60335-2-40:2003 (incl. Corr.:2006) + A11:2004 + A12:2005 + A13:2012 + A1:2006 + A2:2009 with EN 60335-1:2002 + A11:2004 + A1:2004 + A12:2006 + A2:2006 + A13:2008 + A14:2010 + A15:2011).
- Seite 14 WICHTIG! Tod verursachen. • Erden Sie das Gerät gemäß den örtlich zutreffenden Bitte vor Arbeitsbeginn lesen Vorschriften. Diese Klimaanlage entspricht strengen Sicherheits- und • Das Gelbe/Grüne Kabel ist für die ausschließliche Betriebsnormen. Verwendung als Erdleitung. • Verbinden Sie Kabel fest miteinander. Lockere Für den Installateur oder Bediener dieser Anlage ist es Verbindungen können...
- Seite 15 Polyethylenisolierung (r Isolierung min. 8mm). MODELL ENGES ROHR WEITES ROHR AUßENDURCHMESSER MIN. DICKE AUßENDURCHMESSER MIN. DICKE SDIA 6,35 mm 0,8 mm 9,52 mm 0,8 mm 6,35 mm 0,8 mm 0,8 mm SDIB 12,7 mm PVC-Rohr für Kondenswasser-Auslaß (Innen ø 18mm). Es soll lang genug sein, um das Kondenswasser zu einer Außendränung zu leiten.
-
Seite 17: Instrucciones De Instalacion
INSTRUCCIONES DE INSTALACION - Acondicionador de aire Split System - DECLARACION DE CONFORMIDAD Este Producto está marcado porque responde a las Directivas: – Baja Tensión n° 2006/95/CE. (Standard: EN60335-2-40:2003 (incl. Corr.:2006) + A11:2004 + A12:2005 + A13:2012 + A1:2006 + A2:2009 with EN 60335-1:2002 + A11:2004 + A1:2004 + A12:2006 + A2:2006 + A13:2008 + A14:2010 + A15:2011). - Seite 18 ¡IMPORTANTE! • Realizar la puesta a tierra de la unidad siguiendo las normas eléctricas locales. Leer antes de empezar la instalación • El conductor amarillo/verde no se puede utilizar para conexiones que no sean la de tierra. Este sistema de acondicionamiento cumple medidas rígidas •...
- Seite 19 Tubo para refrigeración de cobre recocido y desoxidado, aislado con espuma de polietileno de 8 mm de espesor, para la conexión entre las unidades. MODELO TUBO PEQUEÑO TUBO GRANDE DIAMETRO EXTERIOR ESPESOR MINIMO DIAMETRO EXTERIOR ESPESOR MINIMO SDIA 6,35 mm 0,8 mm 9,52 mm 0,8 mm 6,35 mm 0,8 mm 0,8 mm SDIB 12,7 mm Tubo de PVC para descarga de condensación (ø...
-
Seite 21: Instruções De Instalação
INSTRUÇÕES DE INSTALAÇÃO - Sistema de ar condicionado de Unidades Separadas - DECLARAÇÃO DE CONFORMIDADE Este produto tem a marca porque responde às Directrizes: – Baixa tensão N° 2006/95/CE. (Standard: EN60335-2-40:2003 (incl. Corr.:2006) + A11:2004 + A12:2005 + A13:2012 + A1:2006 + A2:2009 with EN 60335-1:2002 + A11:2004 + A1:2004 + A12:2006 + A2:2006 + A13:2008 + A14:2010 + A15:2011). - Seite 22 IMPORTANTE ! • Ligue a unidade à terra seguindo as normas locais de eletricidade. Queira ler antes de colocar a unidade em funcionamento • O fio AMARELO/VERDE só deve ser usado para ligação Este sistema de ar condicionado satisfaz padrões rigorosos à...
- Seite 23 8mm. MODELO TUBO ESTREITO TUBO LARGO DIÂMETRO EXTERNO ESPESSURA MIN. DIÂMETRO EXTERNO ESPESSURA MIN. SDIA 6,35 mm 0,8 mm 9,52 mm 0,8 mm 6,35 mm 0,8 mm 0,8 mm SDIB 12,7 mm Tubo de PVC para fuga da condensação (diâmetro interno 18mm ) que permite sua condução até...
- Seite 25 O O D D H H G G I I E E S S T T O O P P O O Q Q E E T T H H S S H H S S - D D i i a a i i r r o o u u v v m m e e n n e e " " m m o o n n a a v v d d e e " " k k l l i i m m a a t t i i s s m m o o u u v v - D D H H A A W W S S H H S S U U M M M M O O R R F F W W S S H H S S To proi>ov n autov fev r ei to shv m a diov t i antapokriv n etai sti"...
- Seite 26 S S H H M M A A N N T T I I K K O O ! ! • G G e e i i w w v v s s t t e e t t o o s s u u v v s s t t h h m m a a s s u u v v m m f f w w n n a a m m e e t t o o u u " " i i s s c c u u v v o o n n t t e e " " topikouv " D D i i a a b b a a v v s s t t e e p p r r i i n n a a r r c c i i v v s s e e t t e e t t h h n n e e g g k k a a t t a a v v s s t t a a s s h h hlektrikouv "...
- Seite 27 8 clst. MEGALOSSWLHNAS MIKROS SWLHNAS MONTELO EXWTERIKH DIAMETROS ELACISTO PACOS EXWTERIKH DIAMETROS ELACISTO PACOS SDIA 6,35 mm 0,8 mm 9,52 mm 0,8 mm 6,35 mm 0,8 mm 0,8 mm...
- Seite 28 DIMENSIONS (mm)
- Seite 29 INDOOR UNIT • UNITÀ INTERNA • UNITE INTERIEURE • INNENEINHEIT • UNIDAD INTERIOR • UNIDADE INTERIOR • E E S S W W T T E E R R I I K K H H M M O O N N A A D D A A Find the place for the installation.
- Seite 30 Open a pre-punched hole for the pipe passage (work from outside). Aprire un foro pretranciato per il passaggio delle tubazioni (lavorare dall'esterno). Percer un des trous predécoupés pour le passage des tuyaux (percé par l’extérieur). Ein vorgeschnittenes Loch für die Rohrverlegung öffnen (von außen arbeiten).
- Seite 31 Floor installation. Attach the bracket to the wall with the screws, but do not tighten the screws all the way, so that you can move the bracket for final adjustment. Adjust the bracket as shown in the figure, then finish tightening the screws.
- Seite 32 KIT PARA INSTALAÇÕES À PAREDE OU AO TETO (FORNECIDO COM A UNIDADE) Aparafuse os suportes na parte posterior da unidade usando os parafusos fornecidos com o kit. Procure, nas lojas especializadas, as buchas de fixação compatíveis com a consistência da parede, quatro pedaços de barras com rosca de comprimento adequado (não fornecidas).
- Seite 33 Under ceiling installation. Open a pre-punched hole for the pipe passage (back or botton panel) hole. Fix the unit under the ceiling. Predispose the condensate drain pipe with a positive slope to the outside, as marked on the internal side. Installazione a soffitto.
- Seite 34 Predispose the terminals of the wire to connect to the terminal strip and connect them. (See electric wiring to connect). Secure inter-unit wire using the supplied clamp. WARNING Loose wiring may cause the terminal to overheat or result in unit malfunction.
- Seite 35 Posicione o fio elétrico para a ligação com os terminais e ligue-o (consulte o esquema elétrico para a ligação). Fixe o fio com uma anilha especial à braçadeira. ADVERTÊNCIA Assegure-se que os fios estejam bem apertados a fim de evitar um superaquecimento dos terminais um malfuncionamento da unidade ou mesmo um incêndio.
- Seite 36 Install the condensate drain to the outside with a positive slope. Convogliare la condensa verso l'esterno assicurando una buona pendenza. Diriger les condensats vers l'extérieur, en assurant une bonne pente. Das Kondenswasser-Rohr nach draußen muß mit einer guten Neigung nach unten verlegt werden. Dirigir la condensación hacia fuera asegurando una buena inclinación.
- Seite 37 WIRING DIAGRAM • COLLEGAMENTI ELETTRICI • BRANCHEMENTS ELECTRIQUES • ELEKTRISCHE ANSCHLÜSSE • CONEXIONES ELECTRICAS • INSTALAÇÃO ELÉTRICA • H H L L E E K K T T R R I I K K H H S S U U N N D D E E S S H H TO OUTDOOR UNIT LENGTH, SIZE WIRES AND DELAYED FUSE •...
- Seite 38 Power supply wire A / Connecting wire C (with ground conductor): Multipolar electric wire; size and length of the suggested electric wire are showed on table “electrical data”. The wires have not to be lighter than Mod. H07RN-F (according to CEI 20-19 CENELEC HD22). Make sure the length of the conductors between the fixing point and the terminals allows the straining of the conductors L, N before that of the grounding.
- Seite 39 REMOTE CONTROL UNIT INSTALLATION • POSIZIONE DI INSTALLAZIONE TELECOMANDO • EMPLACEMENT DE LA COMMANDE A DISTANCE • POSITION DER FERNBEDIENUNG • POSICION DE INSTALACION DEL MANDO A DISTANCIA • POSIÇÃO DA INSTALAÇÃO DA UNIDADE DE CONTROLE REMOTO • Q Q E E S S H H T T O O P P O O Q Q E E T T H H S S H H S S T T H H L L E E C C E E I I R R I I S S T T H H R R I I O O U U REMOTE CONTROL UNIT INSTALLATION To ensure that the air conditioner operates correctly, DO NOT install the remote control unit in the following places: •...
- Seite 40 WALL-MOUNTED POSITION • Momentarily place the remote control unit in the desired mounting position. • Verify that the remote control unit can operate from this position. • Fix the support at the wall with two screws and hang the remote control unit. POSIZIONE A PARETE •...
- Seite 41 INFRARED RECEIVER INSTALLATION • INSTALLAZIONE RICEVITORE • INSTALLATION DU RÉCEPTEUR • EMPFÄNGER INSTALLATION • INSTALACIÓN DEL RECEPTOR • INSTALAÇÃO RECEPTOR • E°KATA™TA™H ¢EKTH Y¶EPY£P Slot a screwdriver by the 2 slits on the cover sides, and separate the cover from the base. Do not lay the receiver cable near any power lines, and do not put it into any raceways or metal tubes together with other power lines.
- Seite 42 Perform the earth connection with the terminal on the base, as provided. Complete earth connection and fasten the other end of the cable to the earth terminal in the electric panel. Do not power the system up, and do not start the unit before having completed the refrigerant piping and the electric installation.
- Seite 43 DEFAULT SETTING RESET - RESET IMPOSTAZIONI DI DEFAULT - REMISE A ZERO DES REGLAGES DE DEFAUT - ZURÜCKSETZEN AUF STANDARDEINSTELLUNGEN - RESTABLECER LA CONFIGURACIÓN PREDETERMINADA - RESTABLECIMENTO DAS CONFIGURAÇÕES DE FABRICA - ∂ ·Ó·ÊÔÚ¿ ÛÙ¿ÓÙ·ÚÙ Ú˘ıÌ›ÛÂˆÓ To operate the unit again with the default setting it is necessary to set the remote control as follows: Filter: ON Night Mode / High Power Mode: OFF Operation mode: AUTO...
- Seite 44 Para restablecer las configuraciones predeterminadas de la unidad interior, ustedes tienen que regular el mando a distancia de la manera siguiente: Filter: ON Night Mode / High Power Mode: OFF Modo de funcionamiento: AUTO Flap: AUTO Temperatura seleccionada: 10°C Ahora, presionar simultáneamente los pulsadores del mando a distancia “FAN” y “I FEEL” durante mas de 5 segundos y soltarlos dirigiendo el mando a distancia hacia la unidad interior.
- Seite 45 PUMP DOWN (See Installation Instruction of Outdoor Unit) Pump down means collecting all refrigerant gas in the “Pump down” significa: recuperar todo el gas system back into the outdoor unit without losing gas. refrigerante en la Unidad Exterior sin perder la carga Pump down is used when the unit is to be moved of del Sistema.
- Seite 48 Via Varese, 90 - 21013 Gallarate - Va - Italy Tel. +39 0331 755111 - Fax +39 0331 776240 www.argoclima.com...
