Chopping with the Metal Blade
WARNING:
The chopping blade (19) is very sharp! Danger of injury!
1. Please proceed as described under "Mixing Bowl Operati-
on".
2. Insert the chopping blade (19) directly above the locating
pin. Press the tool down as far as it will go (Fig. 5). Inserting
the tool is easier if it is turned slightly.
3. Cut the food up into smaller pieces beforehand. Now fill in
your ingredients. Please note the quantities stated in the
table below. Do not fill in more or less than the quantities
stated (min. 0.2 kg – max. 1.0 kg).
4. Place the lid in position on the processor bowl. Turn it to the
right until it is heard to lock in place (Illustration 6).
5. Close the filler shaft (8) with the stopper (7) (Illustration 10).
6. Insert the plug into a 230 V / 50 Hz socket installed accor-
ding to existing regulations and with earthing protection.
Switch on the appliance and set a speed between 2 and 3
(See table) with switch (5). You will achieve better results if
you use the pulse mode.
7. After chopping, turn the switch (5) back to "0" and pull out
the plug.
8. To remove the lid, turn it in an anticlockwise direction.
9. Pull the blade off the locating pin.
10. Remove the locating pin from the drive shaft.
11. In order to remove the mixing bowl, turn it in an anticlock-
wise direction. The contents can now be taken out of the
bowl.
12. Clean the used parts as described in "Cleaning".
Cutting and Grating
1. Please proceed as described under "Mixing Bowl Operati-
on".
2. Push to the desired tool (11-15) into the tool holder (17)
(Illustration 7). Attach the tool holder to the locating pin
(Illustration 8).
3. Place the lid in position on the processor bowl. Turn it to the
right until it is heard to lock in place (Illustration 9).
For this you should use the recessed grips of the tool holder.
WARNING:
The grater and rasp surfaces as well as the edges of the
inserts are very sharp! Danger of injury! Handle these
attachments with caution!
4. Insert the plug into a 230 V / 50 Hz socket installed accor-
ding to existing regulations and with earthing protection.
5. Switch the device on (Level 1 or 2 etc.) or use pulse operati-
on "P" (See table).
6. Cut the food up into smaller pieces beforehand. Now fill the
filler shaft (8) with your ingredients. Use the filler (7) to press
the food into the filling slot (Illustration 10). Exert a sufficient
degree of pressure on the filler. The appliance must be swit-
ched on only with the filler (7) mounted into place. Please
note the maximum filling level on the processor bowl.
7. After cutting/grating, turn the switch (5) back to "0" and pull
out the plug.
8. To remove the lid, turn it in an anticlockwise direction.
38
9. Please take off the tool holder from the locating pin.
10. Remove the locating pin from the drive shaft.
11. In order to remove the mixing bowl, turn it in an anticlock-
wise direction. The contents can now be taken out of the
bowl.
12. Clean the used parts as described in "Cleaning".
French fries
Potatoes can be easily and quickly cut into French fries with the
French fry slicer (16).
1. Please proceed as described under "Mixing Bowl Operati-
on".
2. Attach the French fries disc to the locating pin.
CAUTION:
The cutting surfaces and edges of the slicer are extremely
sharp! Danger of injury! Handle these attachments with
caution!
3. Follow points 3 to 5 under "Cutting and Grating".
4. Now fill the filler shaft (8) with your ingredients. Use the filler
(7) to press the food into the filling slot (Illustration 10). Exert
a sufficient degree of pressure on the filler. The appliance
must be switched on only with the filler (7) mounted into
place. Please note the maximum filling level on the proces-
sor bowl.
5. After the cutting process is finished, turn the switch (5) back
to the "0" position and remove the mains plug.
6. To remove the lid, turn it in an anticlockwise direction.
7. Remove the tool carefully from the locating pin.
8. Remove the locating pin from the drive shaft.
9. In order to remove the mixing bowl, turn it in an anticlock-
wise direction. The contents can now be taken out of the
bowl.
10. Clean the used parts as described in "Cleaning".
Using the Whisking and Emulsifying Disc
1. Please proceed as described under "Mixing Bowl Operati-
on".
2. Attach the emulsifying disc (22) directly over the locating pin
(Fig. 11). Press the disc down as far as it will go. Insertion is
easier if the disc is turned slightly.
3. Now put in your ingredients (Fig. 12). Please note the quan-
tities contained in the table below. Do not put in any more or
less than the quantities stated (min. 0.1 l – max. 0.5 l).
4. Place the lid in position on the processor bowl. Turn it tight
until it is clearly heard to lock in place (Illustration 6).
5. Close the opening in the lid with the stopper (7) (Illustration
10).
6. Insert the plug into a 230 V / 50 Hz socket installed accor-
ding to existing regulations and with earthing protection.
Switch on the appliance and set a speed between 1 and 4
(See table) with switch (5).
7. After you have finished beating, turn the switch (5) back to
the "0" position and remove the mains plug.
8. To finish your work, please proceed as described above
under "French fries", points 6 to 10.
