START / STOP / REVERSE function
As with all KINETEC
®
with a START/STOP/REVERSE function.
First, press the hand control switch; the machine stops.
Press the hand control switch again; the mobilization reverses.
For optimum safety, always give the hand control to the patient before starting the system.

Procedure to stop the machine

To stop the machine's movement: press the hand control switch.
To switch the unit off: press the ON / OFF switch (8) (see page 4).

Setting the FLEXION and EXTENSION limits

Select the extension and flexion angles via knob (9) for flexion and
knob (10) for extension.
Modification of the extension or flexion limit can be done while the
machine is running or stationary.
To avoid the parameters being accidentally changed, you are
recommended to close the protective cover on the control panel.
(14).

Setting the SPEED

The SPEED is set by turning knob (11).
At MAXIMUM speed, the machine moves at 145° per minute (for
medium femur length).
At MINIMUM speed, the machine moves at 40° per minute (for medium femur length).
Modification of the speed can be done while the machine is running or stationary.
To avoid the parameters being accidentally changed, you are recommended to close the protective
cover on the control panel (14).
Kinetec Prima Advance™
systems, the device Kinetec Prima Advance™ is equipped
CAUTION
12
13
11
EN
14
9
10
