  • Seite 1 v800−P, v200−P V80GBS..., V20GBD... Montageanleitung Industrie PC, Monitor Mounting Instructions Industrial PC, Monitor...
  • Seite 2 Lesen Sie zuerst diese Anleitung, bevor Sie mit den Arbeiten beginnen! Beachten Sie die enthaltenen Sicherheitshinweise. Please read these instructions before you start working! Follow the enclosed safety instructions.
  • Seite 3: Inhaltsverzeichnis

    ..........Lenze ¯ EDKVX00P242 ¯ 2.0...
  • Seite 4: Über Diese Dokumentation

    Qualifiziertes Fachpersonal sind Personen, die für die auszuführenden Tätigkeiten bei der Aufstellung, Montage, Inbetriebsetzung und dem Betrieb des Produkts über ent- sprechende Qualifikationen verfügen. Tipp! Informationen und Hilfsmittel rund um die Lenze−Produkte finden Sie im Download−Bereich unter www.lenze.com Lenze ¯ EDKVX00P242 ¯ 2.0...
  • Seite 5 Für die Gewährleistung des Personen− und Sachschutzes müssen übergeordnete Sicherheitssysteme eingesetzt werden! Übersicht vx0GB_001 v800−P oder v200−P mit Bildschirmdiagonale 43.9 cm (17.3") v800−P oder v200−P mit Bildschirmdiagonale 61.0 cm (24") Tragarm−Adapter EPCZ... (Zubehör), optional mit Schalterbox (, EDKV800PEPCZ) Lenze ¯ EDKVX00P242 ¯ 2.0...
  • Seite 6 6 = 4 GB 7 = 8 GB Massenspeicher 0 = ohne (Monitor) R = Solid State Disk (SSD) 120 GB Betriebssystem 0 = ohne (Monitor) 9 = Windows® Embedded Standard 7 P, 64 Bit Lenze ¯ EDKVX00P242 ¯ 2.0...
  • Seite 7: Technische Daten

    Core™ i5 − Max. Einschaltstrom Sicherung − 4, träge Celeron® 4, träge 6, träge − Core™ i5 6, träge − Bildschirm Auflösung [Pixel] 1920 x 1080 Seitenverhältnis 16:9 Helligkeit [cd/m Kontrast 600:1 1000:1 600:1 1000:1 Lenze ¯ EDKVX00P242 ¯ 2.0...
  • Seite 8: Mechanische Daten

    61 cm (24") [mm] vx0GB_001 Industrie PC v800−P Monitor v200−P 43.9 cm 61 cm 43.9 cm 61 cm (17.3") (24") (17.3") (24") Masse mit Tragarm−Adapter [kg] 10.9 10.7 mit Tragarm−Adapter und [kg] 12.4 12.2 Schalterbox Lenze ¯ EDKVX00P242 ¯ 2.0...
  • Seite 9: Mechanische Installation

    Ggf. das Display vor Beschädigungen schützen. 2. USB−Abdeckung 1 herausziehen, oben leicht umklappen und Schraube 2 lösen. 3. Service−Schachtdeckel 3 oben nach vorne klappen und abnehmen; USB−Stecker 4 ziehen. 4. Vier Madenschrauben 5 innerhalb des Service−Schachtgehäuses lösen. Schrauben nicht herausdrehen! Lenze ¯ EDKVX00P242 ¯ 2.0...
  • Seite 10 (siehe Schritt 9). 6. Tragarm−Adapter 6 gemäß separater Montageanleitung (, EDKV800PEPCZ) am kundenseitigen Tragarmsystem montieren und verdrahten. vx0GB_002 Abb. 3 Kabel verlegen 7. Anschlusskabel 8 durch die Montageöffnungen führen und nach unten aus dem Service−Schacht heraushängen lassen. Lenze ¯ EDKVX00P242 ¯ 2.0...
  • Seite 11 10.Die vier Madenschrauben 5 von Schritt 4 festziehen. 11.Anschlusskabel 8 aufstecken. vx0GB_002 Abb. 5 Service−Schachtdeckel montieren 12.Service−Schachtdeckel 3 unten aufsetzen, USB−Stecker 4 stecken und Service−Schachtdeckel 3 nach hinten klappen. 13.USB−Abdeckung 1 herausziehen, oben leicht umklappen und Schraube 2 festziehen. Lenze ¯ EDKVX00P242 ¯ 2.0...
  • Seite 12: Elektrische Installation

    1 2 3 Versorgung (24 V Kabel mit Stecker 3−pol. Buchse PHOENIX CONTACT 1 = 0 V/GND PHOENIX CONTACT MC 1.5/3−STF−3.8 2 = PE DFK−MC 1.5/3−GF−3.81 (Leiterquerschnitt max. 1.5 mm 3 = 24 V DC AWG16) vx0GB_003 Lenze ¯ EDKVX00P242 ¯ 2.0...
  • Seite 13: Inbetriebnahme

    Touchscreen einige Zeit deaktivieren, z. B. um den Touchscreen zu reinigen. Touch driver Touchscreen konfigurieren (Single−/Multitouch−Bedienung) Information Device Gerätetyp Serial Number Serien−Nummer des Gerätes Firmware Version Firmware−Version des Gerätes Bios Version Bios−Version des Gerätes (nur v800−P/−C) Image Image−Version des Gerätes (nur v800−P/−C) Lenze ¯ EDKVX00P242 ¯ 2.0...
  • Seite 14 Inbetriebnahme Lenze ¯ EDKVX00P242 ¯ 2.0...
  • Seite 15 ..........Lenze ¯ EDKVX00P242 ¯ 2.0...
  • Seite 16: About This Documentation

    Qualified skilled personnel are persons who have the required qualifications to carry out all activities involved in installing, mounting, commissioning, and operating the product. Tip! Information and tools concerning the Lenze products can be found in the download area at www.lenze.com Application as directed The v800−P/v200−P is used as intended if it is used solely for providing information in...
  • Seite 17 About this documentation Overview vx0GB_001 v800−P or v200−P with screen diagonal 43.9 cm (17.3") v800−P or v200−P with screen diagonal 61.0 cm (24") Support arm adapter EPCZ... (accessories), optionally with switch box (, EDKV800PEPCZ) Lenze ¯ EDKVX00P242 ¯ 2.0...
  • Seite 18 6 = 4 GB 7 = 8 GB Mass storage 0 = without (monitor) R = Solid State Disk (SSD) 120 GB Operating system 0 = without (monitor) 9 = Windows® Embedded Standard 7 P, 64 bits Lenze ¯ EDKVX00P242 ¯ 2.0...
  • Seite 19: Technical Data

    − Max. starting current Fuse − 4, slow−blow Celeron® 4, slow−blow 6, slow−blow − Core™ i5 6, slow−blow − Screen Resolution [pixels 1920 x 1080 Aspect ratio 16:9 Brightness [cd/m Contrast 600:1 1000:1 600:1 1000:1 Lenze ¯ EDKVX00P242 ¯ 2.0...
  • Seite 20: Mechanical Data

    Industrial PC v800−P Monitor v200−P 43.9 cm 61 cm 43.9 cm 61 cm (17.3") (24") (17.3") (24") Mass with support arm adapter [kg] 10.9 10.7 with support arm adapter and [kg] 12.4 12.2 switch box Lenze ¯ EDKVX00P242 ¯ 2.0...
  • Seite 21: Mechanical Installation

    3. Fold the top service shaft cover 3 to the front and remove it; pull the USB plug 4. 4. Loosen four set screws 5 inside the service shaft housing. Do not unscrew the screws! Lenze ¯ EDKVX00P242 ¯ 2.0...
  • Seite 22 (, EDKV800PEPCZ) to the support arm system provided by the customer. vx0GB_002 Fig. 3 Lay cables 7. Feed the connecting cable 8 through the mounting openings and let it hang down out of the service shaft. Lenze ¯ EDKVX00P242 ¯ 2.0...
  • Seite 23 12.Put the service shaft cover 3 onto the button, plug the USB plug 4 and fold back the service shaft cover 3. 13.Pull out the USB cover 1, slightly fold the top and tight the screw 2. Lenze ¯ EDKVX00P242 ¯ 2.0...
  • Seite 24: Electrical Installation

    Cable with plug Supply (24 V DC) 3−pole socket PHOENIX CONTACT 1 = 0 V/GND PHOENIX CONTACT MC 1.5/3−STF−3.8 2 = PE DFK−MC 1.5/3−GF−3.81 (Conductor cross−section max. 3 = 24 V DC 1.5 mm , AWG16) vx0GB_003 Lenze ¯ EDKVX00P242 ¯ 2.0...
  • Seite 25: Commissioning

    Information Device Device type Serial Number Serial number of the device Firmware Version Firmware version of the device Bios version Bios version of the device (only v800−P/−C) Image Image version of the device (only v800−P/−C) Lenze ¯ EDKVX00P242 ¯ 2.0...
  • Seite 28 © 01/2016 | EDKVX00P242 | .ST, | 2.0 | TD29 Lenze Automation GmbH Postfach 10 13 52, 31763 Hameln Hans−Lenze−Str. 1, 31855 Aerzen GERMANY HR Hannover B 205381 Ü +49 5154 82−0 Ø +49 5154 82−2800 Ù lenze@lenze.com Ú www.lenze.com Û...
