... any technical problems or other questions you need clarified? Please contact: • our Help Desk • your sales partner • your sales outlet The latest information on our products, tips, updates, etc., can be found on the Internet under: "http://ts.fujitsu.com" Help Desk list on the internet: "http://ts.fujitsu.com/helpdesk"...
Seite 4
Published by Fujitsu Technology Solutions GmbH A26361-D2156-Z212-1-8N19, Edition 1 2009/05 Produced by XEROX Global Services...
Seite 5
Mainboard D2156 - Internal connectors and slots USB - dual channel Fan 1 Floppy disk drive Serial2 1 = VCC x Front panel 2 = VCC y 3 = Data negative x 4 = Data negative y Additional power supply +12 V...
Seite 6
FAN monitored PSU** / CPU (FAN1) / FAN2 / FAN3 / FAN4 FAN controlled PSU** / CPU (FAN1) / FAN2 / FAN3 / FAN4 TEMP monitored CPU/ONB1/ONB2/HDD SmartCard SystemLock (USB / serial) Fujitsu Technology Solutions Keybord Power Button Support List of special onboard features D2156-A...
Die Position der externen Ansschlüsse Ihres Mainboards finden Sie am Anfang des Handbuches. PS/2-Tastaturanschluss, violett Serielle Schnittstelle, türkis Parallele Schnittstelle/Drucker, burgund PS/2-Mausanschluss, grün LAN-Anschluss (RJ-45) Mikrofonanschluss, rosa Audioeingang (Line in), hellblau USB - Universal Serial Bus, schwarz Audioausgang (Line out), hellgrün A26361-D2156-Z212-1-8N19, Ausgabe 1 Deutsch - 1...
Intel Celeron D mit 533 MHz Front Side Bus in der Bauform LGA775 • Eine aktuelle Liste der von diesem Mainboard unterstützten Prozessoren finden Sie im Internet unter: "http://ts.fujitsu.com/mainboards". Fassen Sie auf keinen Fall die Unterseite des Prozessors an. Schon leichte Verunreinigungen wie Fett von der Haut können die Funktion des Prozessors beeinträchtigen oder den Prozessor zerstören.
Seite 9
Der Steckplatz für Prozessor ist zum Schutz der Federkontakte mit einer Schutzkappe abgedeckt. Im Garantiefall kann das Mainboard nur mit befestigter Schutzkappe von Fujitsu Technology Solutions zurück genommen werden! ► Entfernen Sie den Kühlkörper. ► Drücken Sie auf den Hebel und haken Sie ihn aus.
Modulgröße 256, 512 oder 1024 MByte pro Modul Eine aktuelle Liste der für dieses Mainboard empfohlenen Speichermodule finden Sie im Internet unter: "http://ts.fujitsu.com/mainboards". Es muss mindestens ein Speichermodul eingebaut sein. Speichermodule mit unterschiedlicher Speicherkapazität können kombiniert werden. Es dürfen nur ungepufferte 1,8 V-Speichermodule ohne ECC verwendet werden.
Die Zuordnung der PCI-Interrupts zu den IRQ Lines finden Sie in der folgenden Tabelle: On board controller 1 (A) 2 (B) 3 (C) 4 (D) 5 (E) 6 (F) 7 (G) 8 (H) PCI INT LINE USB 1.1 USB 2.0 SMBus HD Audio A26361-D2156-Z212-1-8N19, Ausgabe 1 Deutsch - 5...
Seite 12
Sharing benutzen müssen, überprüfen Sie, ob die Erweiterungskarte IRQ Sharing mit den anderen Geräten auf dieser PCI IRQ Line einwandfrei unterstützt. Auch die Treiber aller Karten und Komponenten an dieser PCI IRQ Line müssen IRQ Sharing unterstützen. 6 - Deutsch A26361-D2156-Z212-1-8N19, Ausgabe 1...
Kurzbeschreibung des Mainboard BIOS-Update Wann sollte ein BIOS-Update durchgeführt werden? Fujitsu Technology Solutions stellt neue BIOS-Versionen zur Verfügung, um die Kompatibilität zu neuen Betriebssystemen, zu neuer Software oder zu neuer Hardware zu gewährleisten. Außerdem können neue BIOS-Funktionen integriert werden. Ein BIOS-Update sollte auch immer dann durchgeführt werden, wenn ein Problem besteht, das sich durch neue Treiber oder neue Software nicht beheben lässt.
1280 x 1024 32 bit 1600 x 1200 16 bit 1920 x 1440 16 bit 2048 x 1536 16 bit 1366 x 768 32 bit 1024 x 512 32 bit 852 x 480 32 bit 8 - Deutsch A26361-D2156-Z212-1-8N19, Ausgabe 1...
Serial port, turquoise Parallel port/Printer, burgundy PS/2 mouse port, green LAN port (RJ-45) Microphone port, pink Audio input (Line in), light blue USB - Universal Serial Bus, black Audio output (Line out), light green A26361-D2156-Z212-1-8N19, edition 1 English - 1...
If one or more spring contacts are bent do not insert the processor in any case as it may be damaged by doing so. Please contact the responsible vendor. 2 - English A26361-D2156-Z212-1-8N19, edition 1...
Seite 17
Procedure The processor slot is covered with a protective cap to protect the spring contacts In a warranty case the mainboard can only be taken back by Fujitsu Technology Solutions with the protective cap secured! ► Remove the heat sink.
256, 512 or 1024 Mbyte for one module A current list of the memory modules recommended for this mainboard is available on the Internet at: "http://ts.fujitsu.com/mainboards". At least one memory module must be installed. Memory modules with different memory capacities can be combined.
The assignment of the PCI interrupts to the IRQ Lines is shown in the following table: On board controller PCI INT LINE 1 (A) 2 (B) 3 (C) 4 (D) 5 (E) 6 (F) 7 (G) 8 (H) USB 1.1 USB 2.0 SMBus HD Audio A26361-D2156-Z212-1-8N19, edition 1 English - 5...
Seite 20
PCI/PCI Express slot with IRQ sharing, check whether the expansion card properly supports IRQ sharing with the other devices on this PCI IRQ Line. The drivers of all cards and components on this PCI IRQ Line must also support IRQ sharing. 6 - English A26361-D2156-Z212-1-8N19, edition 1...
Brief description of the mainboard BIOS update When should a BIOS update be carried out? Fujitsu Technology Solutions makes new BIOS versions available to ensure compatibility with new operating systems, new software or new hardware. In addition, new BIOS functions can also be integrated.
Seite 22
1280 x 1024 32 bit 1600 x 1200 16 bit 1920 x 1440 16 bit 2048 x 1536 16 bit 1366 x 768 32 bit 1024 x 512 32 bit 852 x 480 32 bit 8 - English A26361-D2156-Z212-1-8N19, edition 1...
Interface série, turquoise Port parallèle/imprimante, bordeaux Port souris PS/2, vert Port LAN (RJ-45) Port microphone, rose Entrée audio (Line in), bleu ciel USB - Universal Serial Bus, noir Sortie audio (Line out), vert clair A26361-D2156-Z212-1-8N19, édition 1 Français - 1...
• Vous trouverez une liste actualisée des processeurs supportés par cette carte mère sur Internet à l’adresse suivante : "http://ts.fujitsu.com/mainboards". Ne touchez jamais la face inférieure du processeur. De légères salissures comme le gras de la peau peuvent perturber le fonctionnement du processeur ou le détruire.
Seite 25
L’emplacement réservé au processeur est recouvert d’un capot protecteur qui protège les broches. En cas de garantie, la carte mère sera uniquement acceptée par Fujitsu Technology Solutions si le capot protecteur est en place ! ► Retirez le refroidisseur. ► Appuyez sur le levier et écartez-le.
Seite 26
256, 512 ou 1024 Moctets par module Vous trouverez une liste actualisée des modules mémoire recommandés pour cette carte mère sur Internet à l’adresse suivante : "http://ts.fujitsu.com/mainboards". Au moins un module mémoire doit être monté. Il est possible de combiner des modules mémoire de capacités différentes.
Seite 27
L’affectation des interruptions PCI aux lignes IRQ est reprise dans le tableau suivant : On board controller PCI INT LINE 1 (A) 2 (B) 3 (C) 4 (D) 5 (E) 6 (F) 7 (G) 8 (H) USB 1.1 USB 2.0 SMBus HD Audio A26361-D2156-Z212-1-8N19, édition 1 Français - 5...
Seite 28
Sharing, vérifiez si la carte d’extension supporte intégralement l’IRQ Sharing avec les autres périphériques sur cette ligne IRQ PCI. Les pilotes de toutes les cartes et composants de cette ligne IRQ PCI doivent également supporter l’IRQ Sharing. 6 - Français A26361-D2156-Z212-1-8N19, édition 1...
Seite 29
Setup du BIOS: mise à jour Quand une mise à jour du BIOS est-elle nécessaire ? Fujitsu Technology Solutions propose de nouvelles versions du BIOS afin de garantir la compatibilité avec les nouveaux systèmes d’exploitation, les nouveaux logiciels ou le nouveau matériel.
Seite 30
1280 x 1024 32 bits 1600 x 1200 16 bits 1920 x 1440 16 bits 2048 x 1536 16 bits 1366 x 768 32 bits 1024 x 512 32 bits 852 x 480 32 bits 8 - Français A26361-D2156-Z212-1-8N19, édition 1...
Seite 31
"User Documentation" или "OEM Mainboard" или же в Internet. Порты и разъемы Информацию о расположении портов и разъемов на Вашей материнской плате Вы найдете в начале Руководства по эксплуатации. Помеченные компоненты и штекерные разъемы могут отсутствовать на материнской плате. A26361-D2156-Z212-1-8N19, издание 1 Pyccкий - 1...
Intel Celeron D с 533 MГц Front Side Bus в конструктивном исполнении LGA775 • Актуальный список процессоров, поддерживаемых этой материнской платой, Вы найдете в Internet на сайте: "http://ts.fujitsu.com/mainboards". Ни в коем случае не прикасайтесь к нижней стороне процессора. Уже малейшие загрязнения, как например, жир на коже, могут негативно...
Seite 33
Разъем для процессора закрыт защитной пластинкой для защиты пружинных контактов. В случае предъявления гарантийных претензий возвращаемая материнская плата может быть принята только при наличии прикрепленной защитной пластинки фирмы Fujitsu Technology Solutions! ► Удалите радиатор. ► Нажмите на рычаг и поднимите его.
Seite 34
памяти модулей Актуальный список модулей памяти, рекомендованных для этой материнской платы, Вы найдете в Internet на сайте: "http://ts.fujitsu.com/mainboards". Необходимо встроить хотя бы один модуль памяти. Можно комбинировать модули памяти с различной ёмкостью ЗУ. Допускается применение только модулей памяти без буферизации 1,8 В без ECC.
Seite 35
Эти расширительные платы требуют до четырех PCI-прерываний: INT A, INT B, INT C, INT D. Информацию о том, сколько прерываний и какие из них используются, Вы найдете в документации, поставляемой вместе с платой. Назначение прерываний PCI на IRQ Lines Вы найдете в следующей таблице: A26361-D2156-Z212-1-8N19, издание 1 Pyccкий - 5...
Seite 36
другой разъем PCI-/PCI-Express с механизмом IRQ Sharing, убедитесь в том, что расширительная карта безукоризненно поддерживает IRQ Sharing с другими устройствами на этой линии PCI IRQ Line. Также и драйверы всех плат и компонент на этой линии PCI IRQ Line должны поддерживать IRQ Sharing. 6 - Pyccкий A26361-D2156-Z212-1-8N19, издание 1...
Seite 37
Краткое описание материнской платы Обновление BIOS Когда необходимо обновить BIOS? Фирма Fujitsu Technology Solutions предоставляет в распоряжение пользователя новые версии BIOS для того, чтобы обеспечить совместимость с новыми операционными системами, с новым программным обеспечением или с новым техническим обеспечением. Кроме того, имеется возможность для интеграции новых функций BIOS.
Seite 38
1280 x 1024 32 бит 1600 x 1200 16 бит 1920 x 1440 16 бит 2048 x 1536 16 бит 1366 x 768 32 бит 1024 x 512 32 бит 852 x 480 32 бит 8 - Pyccкий A26361-D2156-Z212-1-8N19, издание 1...
Seite 39
Paralel bağlantı yeri / Yazıcı, burgunt PS/2-Fare bağlantı yeri, yeşil LAN-bağlantısı (RJ-45) Mikrofon bağlantı yeri, pembe Audio girişi (Line in), açık mavi USB - Üniversel Seriyel Bus, siyah Audio çıkışı (Line out), açık yeşil A26361-D2156-Z212-1-8N19, basım 1 Türkçe - 1...
İşlemci yuvasının yaylı kontakları çok hassas olduğundan ve bükülmeleri yasak olduğundan işlemciyi çok itinalı bir şekilde yuvasına oturtun. Bir veya birden fazla yaylı kontak bükülmüşse işlemciyi kesinlikle yerleştirmeyin, aksi takdirde işlemciye hasar verilebilir. Lütfen direkt olarak sizin için yetkili satıcıya başvurun 2 - Türkçe A26361-D2156-Z212-1-8N19, basım 1...
Seite 41
Ana kartın kısa tanımı İzlenecek yol İşlemcinin yuvası yaylı kontakların korunması için bir koruyucu kapakla örtülmüştür. Garanti durumunda anakartın yalnızca koruyucu kapak takılı vaziyette ise Fujitsu Technology Solutions tarafından geri alınması mümkündür! ► Soğutma bloğunu çıkarın. ► Mandalın üzerine bastırın ve yerinden çıkarın.
Seite 42
1 Takılı olan bellek modülü sayısı Kullanılacak yerler Kanal A, Soket 1 Kanal A, Soket 3 Kanal B, Soket 2 Kanal B, Soket 4 Takma/sökme işlemi "Ana kart temel bilgile”" el kitabında açıklanmıştır. 4 - Türkçe A26361-D2156-Z212-1-8N19, basım 1...
Seite 43
Hangi PCI-Interrupt’ın hangi IRQ Line’larına ait olduğu aşağıdaki tabloda gösterilmiştir: On board kumanda PCI INT LINE 1 (A) 2 (B) 3 (C) 4 (D) 5 (E) 6 (F) 7 (G) 8 (H) USB 1.1 USB 2.0 SMBus HD Audio A26361-D2156-Z212-1-8N19, basım 1 Türkçe - 5...
Seite 44
Eğer IRQ Sharing ile başka bir PCI-/PCI express yuvayı kullanmak zorunda kalırsanız, genişletme kartının, başka aygıtlarla IRQ Sharing’i bu PCI IRQ Line’ı üzerinde kusursuz bir şekilde destekleyip desteklemediğini kontrol edin. Bu PCI IRQ Line’ı üzerindeki tüm kartların ve komponentlerin sürücüleri de IRQ Sharing’i desteklemek zorundadır. 6 - Türkçe A26361-D2156-Z212-1-8N19, basım 1...
Seite 45
Ne zaman bir BIOS-Update yapılmalıdır? Yeni işletim sistemlerine, yeni yazılımlara veya yeni donanımlara uyumluluğu garantilemek için Fujitsu Technology Solutions yeni BIOS versiyonlarını kullanıma sunmaktadır. Bunun dışında yeni BIOS fonksiyonlarının entegre edilmesi mümkündür. Bir sorunun yeni sürücü (driver) veya yeni yazılım sayesinde giderilemediği durumlarda da daima BIOS-Update gerçekleştirilmelidir.
Seite 46
1280 x 1024 32 bit 1600 x 1200 16 bit 1920 x 1440 16 bit 2048 x 1536 16 bit 1366 x 768 32 bit 1024 x 512 32 bit 852 x 480 32 bit 8 - Türkçe A26361-D2156-Z212-1-8N19, basım 1...
