GB
6.3 Operation/Operating pressure
Connect the pneumatic stapler/nailer to the
compressed air connection (Fig. 1 / Item B).
Set the swivel air outlet (Fig. 1 / Item K) to the
desired position.
Before starting the stapler, switch on the
compressor and set the operating pressure on
the pressure reducer to 4 bar.
The knurled screw (Fig. 6 / Item G) for precision
adjustment must be approximately in the middle
position between Item 1 and 2. To do so, turn
open the knurled screw three revolutions, starting
from Position 1.
For the purpose of setting the operating pressure
it is advisable to use a test workpiece which is
similar in structure and material thickness to the
workpieces to be joined.
To staple/nail, place the pneumatic stapler/nailer
against the workpiece and pull the trigger lever
(Fig. 1 / Item A) once and release it again after
each shot.
If the nail or the staple goes in too deep, reduce
the operating pressure on the pressure reducer
by 0.5 bar.
If the nail or the staple does not go in deep
enough or projects, increase the operating
pressure on the pressure reducer by 0.5 bar.
Place the stapler/nailer against the test workpiece
again and fire.
Depending on results, keep changing the
operating pressure in 0.5 bar increments until the
depth that the staples or nails are driven in is
roughly correct. For precision adjustment (Para.
7.4), use the knurled screw.
The equipment also has an automatic mode. If
you keep the trigger lever pressed, the
staples/nails will be shot automatically when the
pneumatic stapler/nailer is placed against the
workpiece.
To prevent faults, make sure that you do not
staple at the same point twice.
Important:
If a staple or nail becomes jammed in the feed shaft,
always immediately depressurize the equipment first
(remove the compressed air supply hose), open the
magazine shaft and only then remove the cover
plates (Fig. 8 / Item I/J) by undoing the screws with
the supplied Allen keys (Fig. 2 / Item N) (Fig. 7 / 8).
Remove the jammed staples, clean the shaft if
necessary, and close again in reverse order.
6.4 Precision adjustment
The equipment has a depth setting adjuster (Fig.
6 / Item G) in the form of a knurled screw.
If you screw it downwards (Fig. 6 / Item 1), the
staples/nails will be shot in deeper.
14
07.09.2011 13:33 Uhr Seite 14
If you want to reduce the depth that the
staples/nails are shot in, you have to screw the
knurled screw upwards (Fig. 6 / Item 2).
Important: To prevent triggering unintentionally, the
depth setting must never be pulled back by hand in
normal operation.

7. Care and maintenance

Important: Disconnect the equipment from the
compressed air system each time before starting to
carry out maintenance and cleaning work.
Compliance with the maintenance instructions given
here will ensure that this quality product has a long
service life and offers failure-free operation.
Before starting work each time, check that the
magazine is securely fastened (Fig. 1/Item E). Clean
the equipment thoroughly immediately after you have
finished the work.
To ensure that your stapler offers lasting perfect
service, it requires regular lubrication. Use the
supplied oil (Fig. 2 / Item M) for this purpose.
There are two possible means of lubrication:
7.1 By mist oiler
A complete conditioning unit contains a mist oiler and
is fitted to the compressor.
7.2 By hand
If your system has neither a conditioning unit or a line
oiler, 3-5 drops of oil have to be applied to the
compressed air connection each time before the air
tool is started up. If the air tool is not used for several
days, apply 5-10 drops of oil to the compressed air
connection before switching on.
Store your air tool in a dry room only.
7.3 Other maintenance work
There are no parts inside the equipment which
require additional maintenance.
