2.

DESCRIPTION OF THE INSTRUMENT

2.1. Description of the front and rear panels

1
600 III 100
2
8
50 60Hz
3
9
4
5 10
MAX ZERO
6
7 11
1 Jaws
2 Protective guard
3 Trigger
4 MAX function
5 Backlighting function
6 Display unit
7 COM input terminals
8 HOLD function / 50-60Hz filter
9 Switch
10 Display reset (zero) key
11 + Input terminals
12 Battery well
22
English
WARNING
IEC 1010 600V CAT I I I
POLLUTION DEGREE 2
12
F 62
