PCE Instruments F 65 Bedienungsanleitung Seite 18

English
TABLE OF CONTENTS
1. GENERAL INSTRUCTIONS ......................... 19
1.1. Precautions and safety measures .............. 19
1.1.1. Before use...............................................19
1.1.2. While in use.............................................20
1.1.3. Symbols ..................................................20
1.1.4. Instructions..............................................20
1.1.5. Maintenance............................................20
1.2. Warranty .................................................... 21
1.3. Maintenance .............................................. 21
1.4. Unpacking - Repacking .............................. 21
2. DESCRIPTION OF THE INSTRUMENT ....... 22
2.1. Description of the front and rear panels ..... 22
2.2. Description of the display unit .................... 23
3. GENERAL DESCRIPTION............................ 24
3.1. Preparation for use..................................... 24
3.1.1. Power supply...........................................24
3.1.2. Installation and replacement of the batteries
24
3.2. Automatic ranges ....................................... 24
3.3. MAXIMUM value (MAX) ............................. 24
3.4. Hold mode (HOLD) .................................... 24
3.5. Relative values (ZERO).............................. 25
3.6. 50-60Hz filter.............................................. 25
3.7. Automatic shut-off (instrument) .................. 25
3.8. Backlighting................................................ 25
4. FUNCTIONAL DESCRIPTION ...................... 25
4.1. Alternating current measurement (A range)25
4.2. Leakage current measurement (mA range) 27
4.3. AC and DC voltage measurements ............ 28
4.4. Resistance measurement........................... 28
4.5. Audible continuity test ................................ 29
4.6. Frequency measurement (Hz).................... 30
5. SPECIFICATIONS ........................................ 31
5.1. General ...................................................... 31
5.2. Characteristics ........................................... 31
5.2.1. AC current (automatic ranges) ................31
5.2.2. mAC current (automatic ranges) .............31
5.2.3. AC voltage (automatic ranges) ................31
5.2.4. DC voltage (automatic ranges)................31
5.2.5. Resistance (Ω) and continuity .................32
5.2.6. Frequency (automatic ranges).................32
5.2.7. Safety ...................................................32
5.2.8. General information.................................32
5.3. Environment ............................................... 33
5.3.1. Temperature............................................33
5.3.2. EMC ...................................................33
5.4. To order ..................................................... 33
18 F 62
